14. Insert tool as shown and press down on both sides of tool
(Fig.12.1) to compress spring kit, then insert top of spring kit
onto top hinge pin (Fig. 12.2).
Fig. 12
1
2
1
Adjusting Hinge Closure Force
1. Remove the tool and insert it (Phillips screwdriver, Allen key,
drift pin) into hole nearest the hinge bracket (Fig.13).
Fig. 13
2. Rotate top of spring counter-clockwise to increase the spring
torque (Fig.14).
Fig. 14
REF1/REF2 Compact Refrigerators 9
