Foundry Networks FES2402 - Physical Dimensions and Weight; Environmental Considerations; Electrical Specifications

Hardware Specifications
December 2008 © 2008 Foundry Networks, Inc. 7 - 13
Physical Dimensions and Weight
Environmental Considerations
Electrical Specifications
Table 7.9 lists the electrical specifications for the power supplies.
Table 7.7: Physical Dimensions and Weight of Power Supplies
Power Supply Dimensions Weight
RPS5
RPS-X424
2.46 in (H) x 8.67 in (W) x 7.6 in (D)
6.25 cm (H) x 22.03 cm (W) x 19.30 cm (D)
4.25 lbs (1.93 kg)
RPS5DC
RPSDC-X424
2.36 in (H) x 8.04 in (W) x 6.45 in (D)
5.99 cm (H) x 20.42 cm (W) x 16.38 cm (D)
4.25 lbs (1.93 kg)
RPS8
RPS8DC
RPSDC-X424-POE
RPS-FGS
RPS-X424-POE
RPS-X448
RPSDC-X448
2.46 in (H) x 8.67 in (W) x 7.6 in (D)
6.25 cm (H) x 22.03 cm (W) x 19.30 cm (D)
6 lbs (2.72 kg)
Table 7.8: Environmental Considerations for Power Supplies
Property RPS5, RPS5DC, RPS-X424, and
RPSDC-X424
RPS8, RPS8DC, RPSDC-X424-
POE, RPS-FGS, RPS-X424-POE,
RPS-X448, and RPSDC-X448
Operating Environment
Operating temperature
32
° to 104° F, 0 ° to 40° C32° to 104° F, 0 ° to 40° C
Operating relative
humidity
0 – 95%, non-condensing 0 – 95%, non-condensing
Operating altitude up to 6,600 feet above sea level up to 10,000 feet above sea level
Operating noise
(based on ISO 7779)
47 dB-A 51 dB-A
Cooling AC: internal fan, 50 mm
DC: internal fan, 60 mm
internal fans, 50mm
Storage Environment
Storage temperature
-40
° to 185° F, - 4 0 ° to +85° C-40° to 185° F, - 40 ° to +85° C
Storage altitude up to 15,000 feet above sea level up to 15,000 feet above sea level
