Input Connector and Plug
Table 7.10 lists the input connectors for the power supplies.
Table 7.10: Input Connector for Power Supplies
Table 7.9: Power Supply Electrical Specification Ranges
Description RPS5 and RPS-
X424
RPS5DC and
RPSDC-X424
RPS8, RPS-FGS,
RPS-X424-POE,
and RPS-X448
RPS8-DC, RPSDC-
X424-POE, and
RPSDC-X448
Input Specifications
Input voltage
range
100 - 240 VAC -40 to -60 VDC 100 to 240 VAC -48 to -60 VDC
Input current < 3.5 Amps < 9 Amps <8 Amps <18 Amps
Inrush current < 4.2 Amps peak
maximum
<10 Amps peak
maximum < 150 ms
(0.15 seconds)
< 11.25 Amps peak
maximum
< 26 Amps peak
maximum
Output Specifications
Output power 220 watts of total output power 600 watts of total output power, including
+12VDC @ 10A to the system and -48VDC
@ 10 A for Power over Ethernet
applications
Power Supply Input Connector Properties
All AC Power
Supplies
Standard IEC type (IEC 320)
C14 type: UL/CSA 15A/250V, VDE 10A/250V
Orientation: Ground pin down
All DC Power
Supplies
3-position Phoenix Contact
The power supply is connected to Earth Ground using wire attached to the
ground stud on the power supply rear panel.
