Hardware Specifications
December 2008 © 2008 Foundry Networks, Inc. 7 - 15
Figure 7.4 shows the power plug and connector for AC power supplies.
Figure 7.4 AC power cable plug and input connector
Figure 7.5 shows the power connector for DC power supplies.
Figure 7.5 DC power connector
Regulatory Compliance
This section contains regulatory standards for the power supplies, including the following:
• Electromagnetic Compatibility (EMC) compliance
• Immunity regulations
• Safety certifications
• Safety warning labels
• Environmental standards
- 48 VDC Lead
10 AWG Wire
48 RTN Lead
Negative Terminal Screw
Positive Terminal Screw
