F3D3 Series Service Manual - General Service Instructions / Section 2.1
Questions? Call Franke Technical Support Group For Your Area. -2- Copyright  2012 Franke, Inc. All rights reserved.
Suggested [On-Truck] Repair Parts:
We suggest the following to ensure first-trip fix of F3D3 Units:
120V/60Hz 230V/50Hz Description Quantity
19003748 19003748 Freezer Door Gasket 1
19002708 19002708 Drum/Door-Lift/Door-Open Motors 2
19002732 19002732 Load Cell 1
19000192 19000192 Door-Open Sensor 1
19003900 19003900 Operator Touch Pad Control Panel 1
385.151 385.151 Main Power Switch 1
19003762 19003762 Siemens 24-Volt Power Supply 1
19003424 19003899 F3D3S Main Control Board 2
19000384 19000384 Low Product Sensor 1
19003042 19003042 SPST Sensor/Actuator Set 2
18003285 18003285 Kit, Drive Shaft Rotor Repair 2
18004999 18004999 Kit, Spring & Link Repair 2
19003534 18003534 Product Door 2
19000247 19000247 Product Baffle 2
19001253 19001086 Condenser Fan Motor 1
19001082 19001080 Start Relay 2
19001085 19001254 Motor Start Capacitor 2
19001190 19001190 Thermostatic Expansion Valve 1
19003221 19003222 Condenser/Compressor 1
19000801 19000826 Cord Set [10-foot] 1
19003756 19003756 Condenser Air Filter 1
NOTE: Part numbers are subject to change, as product
improvements are implemented.
When In Doubt…
Call the Franke Technical Support Group for your area.

Tools Required:
[For Mechanical Systems Repair]
 10 mm [3/8”] flat screwdriver
 6-7 mm [¼”] flat screwdriver
 2 mm [1/16” ] flat screwdriver
 Small & Medium Phillips screwdrivers
 3 mm [1/8”] Allen/hex wrench
 4 mm [5/32”] Allen/hex wrench
 5 mm [3/16”] Allen/hex wrench
 13 mm Allen/hex wrench
 9 mm wrench or socket
 11 mm [7/16”] box/socket wrench
 Razor knife
 Needle nose pliers
 ‘C’ ring pliers
 Small wire cutters
 Rubber mallet
 Feeler or Gap Gauge
 Plastic Wire Ties
