Freestyle 80 - Page 14

Part number 550-142-850/0716
14
FreeStyle
®
WALL MOUNT GAS-FIRED WATER BOILER — Boiler Manual
3. ,OOSENTHEBOTTOMSWIVELNUTOFGASPIPEANDUNSCREWTHE
TOPSWIVELNUTh!vFigure 13,)TEMFROMTHEGASVALVEVENTURI
Figure 13, Item 6.
Figure 13 'ASVALVEVENTURIREPLACEDFORPROPANE
CONVERSION#ONTROLPANELREMOVEDFORCLARITY
Figure 14 ,0VENTURIINSTALLEDTOBLOWER
4 Converting boiler to propane continued
,%'%.$FORFigures 12, 13, 14 and 15
1 Control panel (page 13)
2 Gas valve (page 13)
3 Gas pipe
4 Washer
5 Hex head screws
6 Gas valve venturi
“O” Ring
8 Blower
4. Remove three (3) Hex head screws holding the venturi,
Item 5 in place, remove venturi, replace with new propane
VENTURIFROMKIT6ERIFYTHEVENTURILABELINFORMATION
matches the boiler size (80, 120 or 155).
(Propane venturi has black label), ensure Item 7, venturi “O”
ring is in place (see Figure 16), re-insert three (3) Hex head
screws to hold new venturi, tighten to hold securely in place.
5. Reassemble gas pipe and new washer to the venturi fitting,
RECONNECTNUTh!vANDGASPIPEh)TEMvTOVENTURIANDCHECK
THESEALOFTHECONNECTION
Figure 15
'ASPIPEREASSEMBLEDTO,0VENTURIlTTING
Figure 16 )NSUREh/vRINGISINPLACE
7
A
3
5
4
3
5
8
A
6
3
2
4
5
