WALL MOUNT GAS-FIRED WATER BOILER — Boiler Manual
32 Troubleshooting(continued)
Table 5 FreeStyle
®
LISTOF3YSTEMPARAMETERSDEFAULTSETTINGS
System Parameters list (default settings)
There are 4 basic configurations within the DHW mode, selected by parameter DHW configuration (see Parameters list, Num.
$EFAULTVALUEISANDITREPRESENTSCONlGURATION"YCHANGING$(7CONlGURATIONSEE0ARAMETERSLIST.UMALLTHEDATA
WILLBEAUTOMATICALLYSETATDEFAULTCONDITION0ARAMETERSTHATWILLBECHANGEDACCORDINGTOTHE$(7MODEARENUMBEREDFROM
TOSEE0ARAMETERSLIST!LLTHEPARAMETERSCANBEACCESSEDWITHACOMMUNICATIONPACKAGERUNNINGONTHE0#3OMEPARAM-
ETERSAREAVAILABLEBYTHEINSTALLER430MODEONTHE--)ORBYTHE/42OOMUNIT
Category %PROMPARAMETERS 5NIT 2ANGE $EF
Description
Num. Address Description Low High Value
DHW boiler type 1 CL5 – 05C8  Num 1 4 3
System 2 ML – 80D0  Num 0 1 0
End user setting 3 ML – 80E2 Summer / Winter selection Num 0 1 1
End user setting 4 ML – 80E3 Economy / Comfort selection Num 0 1 0
End user setting 5 CL5 – 0A9D CH set point limit - HIGH °F 68 194 190
End user setting 6 CL5 – 056D CH user set point °F 68 194 158
Exhaust protection 7 CL5 – 050B Maximum exhaust gases temperature °F 32 255 185
Firmware version 8 ML – 80E8 Firmware version Num 0 99 03
 9,1 CL5 – 066E DHW P factor Num 0 255 15
 10,1 CL5 – 0691 DHW I factor Num 0 255 240
 11,1 ML – 80EB DHW FF factor Num 0 255 0
 12,1 ML – 80EC Fan absolute DHW maximum speed Hz 0 220 200
 13,1 ML – 80ED Fan absolute CH maximum speed Hz 0 220 200
 14,1 ML – 80EE Fan absolute minimum speed Hz 0 165 40
 15,1 CL5 – 2D89 Fan offset low level Hz 0 220 10
 16,1 ML – 80F0 Ignition level % 0 100 60
 17,1 ML – 80F1 DHW maximum output boost/limit level % 75 125 100
 18,1 ML – 80F2 DHW maximum output boost/limit time Sec 0 120 60
 19,1 ML – 80F3  °F 68 194 167
 20,1 ML – 80F4  °F 68 194 163
 21,1 ML – 80F5 DHW over-temp_burnerOFF – setpoint °F 0 200 9
 22,1 ML – 80F6 DHW over-temp_burnerON – setpoint °F 0 200 0
 23,1 ML – 80F7 DHW over-temp_burnerOFF – solar °F 0 200 18
 24,1 ML – 80F8 DHW over-temp_burnerON – solar °F 0 200 18
 25,1 ML – 80F9 DHW start waiting time – solar1 Sec 0 255 5
 26,1 ML – 80FA DHW start waiting time – solar2 Sec 0 255 10
 27,1 ML – 80FB DHW start waiting time – solar3 Sec 0 255 20
 28,1 CL5 – 0A5E DHW comfort switch on point °F 0 176 104
 29,1 CL5 – 0A62 DHW comfort on time Sec 0 104 15
 30,1 ML – 80FE DHW comfort off time1 Min 0 255 20
 31,1 ML – 80FF DHW comfort off time2 Min 0 255 42
 32,1 CL5 – 05A1 DHW OFF time Sec 30 255 120
 33,1 CL5 - 0A04 DHW pump over-run time Sec 0 255 3
 34,1 CL5 – 0A6D Delta T1 °F 0 108 32
 35,1 CL5 – 0A92 Delta T2 °F 0 255 63
Figure 1234ROUBLESHOOTINGSUGGESTIONSFORFreeStyle
®
BOILERS&AULTDISPLAYSANDDIAGNOSTICS(continued)
