WALL MOUNT GAS-FIRED WATER BOILER — Boiler Manual
32 Troubleshooting(continued)
Category %PROMPARAMETERS 5NIT 2ANGE $EF
Description
Num. Address Description Low High Value
 36,1 ML – 8104 CH supply for CH pump over-run OFF °F 32 212 122
 37,1 CL5 – 0C94 CH supply for CH pump over-run ON °F 0 200 18
 38,1 ML – 8106 CH supply over-temp_burnerOFF °F 0 212 203
 39,1 ML – 8107 CH supply over-temp_burnerON °F 32 212 194
 40,1 ML – 8108 CH return over-temp_burnerOFF °F 32 212 203
 41,1 ML – 8109 CH return over-temp_burnerON °F 32 212 194
 42,1 ML – 810A DHW set point limit – LOW °F 50 104 104
 43,1 CL5 – 1E76 DHW set point limit – HIGH °F 104 158 131
 44,1 CL5 – 05F4 DHW user set point – Default value °F 50 158 131
 45,1 ML – 810D CH pre-pump time Sec 0 60 30
 46,1 ML – 810E Minimum virtual set point °F 68 176 95
 9,2 CL5 – 066E DHW P factor Num 0 255 5
 10,2 CL5 – 0691 DHW I factor Num 0 255 240
 11,2 ML – 80EB DHW FF factor Num 0 255 0
 12,2 ML – 80EC Fan absolute DHW maximum speed Hz 0 220 200
 13,2 ML – 80ED Fan absolute CH maximum speed Hz 0 220 200
 14,2 ML – 80EE Fan absolute minimum speed Hz 0 165 40
 15,2 CL5 – 2D89 Fan offset low level Hz 0 220 10
 16,2 ML – 80F0 Ignition level % 0 100 60
 17,2 Free - TBD
 18,2 Free - TBD
 19,2 Free - TBD
 20,2 Free - TBD
 21,2 Free - TBD
 22,2 Free - TBD
 23,2 Free - TBD
 24,2 Free - TBD
 25,2 Free - TBD
 26,2 ML – 80FA DHW pre-pump time Sec 0 30 30
 27,2 ML – 80FB Legionella protection Num 0 7 0
 28,2 CL5 – 0A5E DHW comfort hysteresis °F 0 176 4
 29,2 CL5 – 0A62 DHW comfort temp difference °F 0 104 0
 30,2 ML – 80FE DHW pump start temperature °F 0 255 32
 31,2 ML – 80FF DHW pump start waiting time Sec 0 255 0
 32,2 CL5 – 05A1 DHW OFF time Sec 30 255 120
 33,2 CL5 – 0A04 DHW pump over-run time Sec 0 255 30
 34,2 CL5 – 0A6D Delta T1 °F 0 108 32
 35,2 CL5 – 0A92 Delta T2 °F 0 255 63
 36,2 ML – 8104 CH supply for CH pump over-run OFF °F 32 212 68
 37,2 CL5 – 0C94 CH supply for CH pump over-run ON °F 0 200 9
 38,2 ML – 8106 CH supply over-temp_burnerOFF °F 0 212 9
 39,2 ML – 8107 CH supply over-temp_burnerON °F 32 212 176
 40,2 ML – 8108 CH return over-temp_burnerOFF °F 32 212 203
 41,2 ML – 8109 CH return over-temp_burnerON °F 32 212 194
Figure 1244ROUBLESHOOTINGSUGGESTIONSFORFreeStyle
®
BOILERS&AULTDISPLAYSANDDIAGNOSTICS(continued)
