Freestyle 80 - Page 97

Part number 550-142-850/0716
97
FreeStyle
®
WALL MOUNT GAS-FIRED WATER BOILER — Boiler Manual
32 Troubleshooting(continued)
Category %PROMPARAMETERS 5NIT 2ANGE $EF
Description
Num. Address Description Low High Value
 42,2 ML – 810A DHW set point limit – LOW °F 50 104 50
 43,2 CL5 – 1E76 DHW set point limit – HIGH °F 104 158 149
 44,2 CL5 – 05F4 DHW user set point – Default value °F 50 158 149
 45,2 ML – 810D CH pre-pump time Sec 0 60 30
 46,2 ML – 810E Minimum virtual set point °F 68 176 95
 9,3 CL5 – 066E DHW P factor Num 0 255 20
 10,3 CL5 – 0691 DHW I factor Num 0 255 240
 11,3 ML – 80EB DHW FF factor Num 0 255 0
 12,3 ML – 80EC Fan absolute DHW maximum speed Hz 0 220 200
 13,3 ML – 80ED Fan absolute CH maximum speed Hz 0 220 200
 14,3 ML – 80EE Fan absolute minimum speed Hz 0 165 40
 15,3 CL5 – 2D89 Fan offset low level Hz 0 220 10
 16,3 ML – 80F0 Ignition level % 0 100 60
 17,3 ML – 80F1 DHW maximum output boost/limit level % 75 125 100
 18,3 ML – 80F2 DHW maximum output boost/limit time Sec 0 120 60
 19,3 ML – 80F3  °F 68 194 167
 20,3 ML – 80F4  °F 68 194 163
 21,3 ML – 80F5 DHW over-temp_burnerOFF – setpoint °F 0 200 9
 22,3 ML – 80F6 DHW over-temp_burnerON – setpoint °F 0 200 0
 23,3 ML – 80F7 DHW over-temp_burnerOFF – solar °F 0 200 18
 24,3 ML – 80F8 DHW over-temp_burnerON – solar °F 0 200 18
 25,3 ML – 80F9 DHW start waiting time – solar1 Sec 0 255 5
 26,3 ML – 80FA DHW start waiting time – solar2 Sec 0 255 10
 27,3 ML – 80FB DHW start waiting time – solar3 Sec 0 255 20
 28,3 CL5 – 0A5E DHW comfort switch on point °F 0 176 104
 29,3 CL5 – 0A62 DHW comfort temp difference °F 0 100 36
 30,3 ML – 80FE DHW pump start temperature °F 0 255 68
 31,3 ML – 80FF DHW pump start waiting time Sec 0 255 1
 32,3 CL5 – 05A1 DHW OFF time Sec 0 255 120
 33,3 CL5 – 0A04 DHW pump over-run time Sec 0 255 30
 34,3 CL5 – 0A6D Delta T1 °F 0 108 32
 35,3 CL5 – 0A92 Delta T2 °F 0 255 255
 36,3 ML – 8104 CH supply for CH pump over-run OFF °F 32 212 91
 37,3 CL5 – 0C94 CH supply for CH pump over-run ON °F 0 200 18
 38,3 ML – 8106 CH supply over-temp_burnerOFF °F 0 212 203
 39,3 ML – 8107 CH supply over-temp_burnerON °F 32 212 194
 40,3 ML – 8108 CH return over-temp_burnerOFF °F 32 212 203
 41,3 ML – 8109 CH return over-temp_burnerON °F 32 212 194
 42,3 ML – 810A DHW set point limit – LOW °F 50 104 104
 43,3 CL5 – 1E76 DHW set point limit – HIGH °F 104 158 131
 44,3 CL5 – 05F4 DHW user set point – Default value °F 50 158 131
 45,3 ML – 810D CH pre-pump time Sec 0 60 30
 46,3 ML – 810E Minimum virtual set point °F 68 176 95
Figure 1254ROUBLESHOOTINGSUGGESTIONSFORFreeStyle
®
BOILERS&AULTDISPLAYSANDDIAGNOSTICS(continued)
