QUANTUM™ COMPRESSOR CONTROL PANEL S90-010 M
MAINTENANCE Page 115
PRESSURE TRANSDUCER CONVERSION DATA
(Data Instruments Model SA)
100 psi 200 psi 300 psi 500 psi
Range - psig* Range - psig* Range - psig* Range - psig*
Sensor
Voltage
Low High Low High Low High Low High
1.0 29.92" 19.74" 29.92" 9.57" 29.92" 7.0" 29.92” 4.1
1.1 29.92" 14.65" 29.92" 0.3 29.92" 4.1 29.92” 16.6
1.2 29.92" 9.57" 29.92" 5.3 22.3" 11.6 17.1” 29.1
1.3 24.83" 4.48" 19.74" 10.3 7.0" 19.1 4.1 41.6
1.4 19.74" 0.3 9.57" 15.3 4.1 26.6 16.6 54.1
1.5 14.65" 2.8 0.3 20.3 11.6 34.1 29.1 66.6
1.6 9.57" 5.3 5.3 25.3 19.1 41.6 41.6 79.1
1.7 4.48" 7.8 10.3 30.3 26.6 49.1 54.1 91.6
1.8 0.3 10.3 15.3 35.3 34.1 56.6 66.6 104.1
1.9 2.8 12.8 20.3 40.3 41.6 64.1 79.1 116.6
2.0 5.3 15.3 25.3 45.3 49.1 71.6 91.6 129.1
2.1 7.8 17.8 30.3 50.3 56.6 79.1 104.1 141.6
2.2 10.3 20.3 35.3 55.3 64.1 86.6 116.6 154.1
2.3 12.8 22.8 40.3 60.3 71.6 94.1 129.1 166.6
2.4 15.3 25.3 45.3 65.3 79.1 101.6 141.6 179.1
2.5 17.8 27.8 50.3 70.3 86.6 109.1 154.1 191.6
2.6 20.3 30.3 55.3 75.3 94.1 116.6 166.6 204.1
2.7 22.8 32.8 60.3 80.3 101.6 124.1 179.1 216.6
2.8 25.3 35.3 65.3 85.3 109.1 131.6 191.6 229.1
2.9 27.8 37.8 70.3 90.3 116.6 139.1 204.1 241.6
3.0 30.3 40.3 75.3 95.3 124.1 146.6 216.6 254.1
3.1 32.8 42.8 80.3 100.3 131.6 154.1 229.1 266.6
3.2 35.3 45.3 85.3 105.3 139.1 161.6 241.6 279.1
3.3 37.8 47.8 90.3 110.3 146.6 169.1 254.1 291.6
3.4 40.3 50.3 95.3 115.3 154.1 176.6 266.6 304.1
3.5 42.8 52.8 100.3 120.3 161.6 184.1 279.1 316.6
3.6 45.3 55.3 105.3 125.3 169.1 191.6 291.6 329.1
3.7 47.8 57.8 110.3 130.3 176.6 199.1 304.1 341.6
3.8 50.3 60.3 115.3 135.3 184.1 206.6 316.6 354.1
3.9 52.8 62.8 120.3 140.3 191.6 214.1 329.1 366.6
4.0 55.3 65.3 125.3 145.3 199.1 221.6 341.6 379.1
4.1 57.8 67.8 130.3 150.3 206.6 229.1 354.1 391.6
4.2 60.3 70.3 135.3 155.3 214.1 236.6 366.6 404.1
4.3 62.8 72.8 140.3 160.3 221.6 244.1 379.1 416.6
4.4 65.3 75.3 145.3 165.3 229.1 251.6 391.6 429.1
4.5 67.8 77.8 150.3 170.3 236.6 259.1 404.1 441.6
4.6 70.3 80.3 155.3 175.3 244.1 266.6 416.6 454.1
4.7 72.8 82.8 160.3 180.3 251.6 274.1 429.1 466.6
4.8 75.3 85.3 165.3 185.3 259.1 281.6 441.6 479.1
4.9 77.8 87.8 170.3 190.3 266.6 289.1 454.1 491.6
5.0 80.3 90.3 175.3 195.3 274.1 296.6 466.6 504.1
At zero psig 1.388 V 1.788 V 1.094 V 1.494 V 1.046 V 1.346 V 0.968 V 1.268 V
* Below 0 psig measured in inches of mercury.
