S90-010 M FRICK
QUANTUM™ COMPRESSOR CONTROL PANEL
Page 116 MAINTENANCE
RECOMMENDED SPARE PARTS
Part Number Description Spare-1 Spare-2 Spare-3
Control Power
333Q0001194 On/off power switch yes yes
333Q0001195 On/off power switch contact block yes yes
333Q0001327 Fuse, .25 amp, 250 V (main board) yes yes yes
333Q9991418 Filter, Line
333Q0000206 Relay, 3 Pole yes yes yes
333Q0000207 Relay base, 3 Pole yes yes
333Q0001191 Hour meter
333Q0001192 2.5V CT. Transformer for motor current step-down.
111Q0280958 Surge suppresser yes yes yes
Displays (Refer to chart on page 34)
640C0021G01 10.4"diag. LCD color VGA display assembly with backlight (Sharp) yes
2
640C0052G01 10.4"diag. LCD color VGA display assembly with backlight (L.G.Philips) yes
2
CCFT inverter (refer to the chart on page 34)
Back light inverter cable (refer to the chart on page 34) yes
Display cable (refer to the chart on page 34) yes
Harnesses
640B0038H01 DC power harness yes
640B0039H01 Shunting plug yes
649B0862H01 Quantum™ 4 Adapter Harness
Power Supplies
640C0022G01 DC power supply yes yes
640C0022G11 DC power supply (Power-One to Condor) yes yes
Digital Boards
640C0024G01 Digital Input/Output Board #1 yes
640C0024G02 Digital Input/Output Board #2 yes
111Q0281061 Output Module 120/240 volt AC yes yes yes
333Q0000116 Input Module 120 volt AC yes yes yes
333Q0001326 Fuse, 5 amp, 250 V (I/O board) yes yes yes
Analog Boards
640C0026G01 Analog Borad #1 yes
640C0026G02 Analog Board #2 yes
Keypads
640D0060H01
Keypad/overlay Frick
’s
yes
640D0066H01 Keypad/overlay Gram’s yes
640B0031H01 Keypad cable yes
Circuit Breakers
649A0883H10 10 Amp circuit breaker yes
649A0883H16 16 Amp circuit breaker yes
Quantum™ Controllers
649C1083G01 Upgrade from Quantum™ 1, 2 or 3 to Quantum™ 4 yes
1
649C1091G01 Quantum™ 4 to Quantum™ 4 yes
1
649C1092G01 Upgrade from Quantum™ 3 to Quantum™ 4 (in RXF Lite panel) yes
1
649C1093G01 Upgrade from Quantum™ 1, or 2 to Quantum™ 4 (in RXF Lite Panel) yes
1
Notes:
• Note 1 – These processor boards are listed for reference. Each Quantum™ Control will have only one of these boards. Order
only the replacement board that is applicable to your controller, not both boards.
• Note 2 – These displays are listed for reference. Each Quantum™ Control will have only one of these displays. Order only the
replacement display that is applicable to your controller.
• Spare-1 - Normal spare parts kept on hand. Operation can wait more than 24 hours to receive replacement parts.
Plant typically has back-up compressors.
• Spare-2 - Additional spare parts kept on hand. Operation must have parts in less than 24 hours. Plant does not have back-up
compressors.
• Spare-3 - Critical operation. Plant must have continuous operation.
REMANUFACTURED PARTS
Part Number Description
649A0985G01 Quantum™3 to Quantum™ 4
649A0985G11 Quantum™4 to Quantum™ 4
649A0985G21 Digital I/O Board
649A0985G31 Analog I/O Board
649A0985G41 DC Power Supply (Condor to Condor)
649A0985G51 Display Assembly (L.G. Philips to L.G. Philips)
649A0985G61 Display Assembly (Sharp to Sharp)
