Frick QUANTUM 3 - CALIBRATION; Pressure Transducers and Temperature Sensors

S90-010 M FRICK

QUANTUM™ COMPRESSOR CONTROL PANEL
Page 46 MAINTENANCE
CALIBRATION
(while in factory setup)
Pressure Transducers and Temperature Sensors:
Pressure
Transducer
Transducer
High End
(default is
485.3 psig**)
Transducer
Low End
(default is
30.0 hg.)
Sensor Type
1 - 5 Vdc, 0 - 5 Vdc
(default = 1 - 5 Vdc)
Suction**
Discharge
Oil
Filter
System Discharge
Balance Piston
** The default High End for the Suction Pressure Transducer is 185.3 psig.
Temperature
Sensor
Sensor
High End
(default is
463.1 O F)
Sensor
Low End
(default is
-459.4 O F)
Sensor Type
ICTD
1 - 5 Vdc, 0 - 5 Vdc
(default = ICTD)
Suction
Discharge
Oil
Separator
System Discharge
Leaving Process
Entering Process
Remote Control Calibration:
Capacity Control #1 (CC1): ___________
Capacity Control #2 (CC2): ___________
Remote
Setpoint
Top end
Value (20 mA)
Bottom End
Value (4 mA)
CC1
Incoming
CC1
Outgoing
CC2
Incoming
CC2
Outgoing
Calibrate Slide Valve Position Dead Band %: _____ (Default is 1%)
York S7 - Level Position:
Actual Setpoint
Proportional Band
Dead Band
