Frick QUANTUM 3 - ANALOG BOARD SETTINGS

S90-010 M FRICK

QUANTUM™ COMPRESSOR CONTROL PANEL
Page 24 MAINTENANCE
ANALOG BOARD SETTINGS
COMMUNICATIONS SETTINGS
J33
in
out*
RS-422/485 receive pull-down for long
communications lines.
No pull-down
J34
in
out*
RS-422/485 transmit pull-up for long
communications lines.
No pull-up.
J35
in
out*
RS-422 receive pull-down for long
communications lines.
No pull-down.
J36
in
out*
RS-422 transmit pull-up for long
communications lines.
No pull-up.
J37
in
out*
120 ohm long communications line
termination.
No termination.
* standard setting
DIPSWITCH SETTINGS
SW1 SW2 SW3 SW4 SW5
Board #1 On On On On Off
Board #2 Off On On On Off
Board #3 On Off On On Off
Board #4 Off Off On On Off
Board #5 On On Off On Off
Board #6 Off On Off On Off
ANALOG BOARD #1 INPUT JUMPERS
Input Channel #1 - Suction Temperature
J1
out
1-2
2-3*
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #2 - Discharge Temperature
J2
out
1-2
2-3*
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #3 - Oil Temperature
J3 out
1-2
2-3*
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #4 - Oil Separator Temperature
J4
out
1-2
2-3*
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #5 - Leaving Process Temperature**
J5
out
1-2
2-3*
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #6 - Oil Pressure
J6
out*
1-2
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #7 - Oil Filter Pressure**
J7
out*
1-2
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #8 - Discharge Pressure
J8
out*
1-2
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #9 - Suction Pressure
J9
out*
1-2
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #10 - Balance Piston Pressure**
J10
out*
1-2
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #11 - System Discharge Pressure**
J11
out*
1-2
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #12 - Remote Capacity Control Setpoint**
J12
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #13 - Remote Slide Valve Position**
J13
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #14 - Slide Valve** (linear transmitter)
J14
in†
out*
All other Input
types (0-5 volt, 4-20 mA,
ICTD)
Slide valve potentiometer Input.
J15
out*
1-2 †
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
J16
in†
out*
All other Input
types (0-5 volt, 4-20 mA,
ICTD)
Slide valve potentiometer Input.
Input Channel #15 - Slide Stop**
J17
in†
out*
All other Input
types (0-5 volt, 4-20 mA,
ICTD)
Slide stop potentiometer Input.
J18
out*
1-2†
2-3†
0-5 volt Input
4-20 mA Input
ICTD Input
J19
in†
out*
All other Input
types (0-5 volt, 4-20 mA,
ICTD)
Slide valve potentiometer Input.
Input Channel #16 - Motor Amps
J20 J21 J22
0-5 amp CT Input* out out in
0-5 volt Input out out out
4-20 mA Input in out out
ICTD Input out in out
* standard setting
** = If applicable
† = RWF compressor standard setting
