FRICK
QUANTUM™ COMPRESSOR CONTROL PANEL S90-010 M
MAINTENANCE Page 25
ANALOG BOARD #1 OUTPUT JUMPERS
Output Channel #1 - PID / Programmable
J26
1-2
2-3
0-20 mA Output
4-20 mA Output
J39
1-2
2-3
4-20 mA Output
0-20 mA Output
IC’s install U15 & U7 Connect to P10 terms 1 & 2
Output Channel #2 - PID / Programmable
J25
1-2
2-3
0-20 mA Output
4-20 mA Output
J40
1-2
2-3
4-20 mA Output
0-20 mA Output
IC’s install U15 & U6 Connect to P10 terms 3 & 4
Output Channel #3 - Programmable
J24
1-2
2-3*
0-20 mA Output
4-20 mA Output
J41
1-2*
2-3
4-20 mA Output
0-20 mA Output
IC’s install U15 & U5 Connect to P10 terms 5 & 6
Output Channel #4 – Remote Control Setpoint**
J23
1-2
2-3*
0-20 mA Output
4-20 mA Output
J42 1-2*
2-3
4-20 mA Output
0-20 mA Output
IC’s install U15 & U4 Connect to P10 terms 7 & 8
* = Standard Setting
** = If applicable
Note: IC’s must also be installed in order to enable the
analog output options. U15 along with at least one IC
(U4,U5,U6 or U7) installed will enable the channel.
ANALOG BOARD #2 INPUT JUMPERS
Input Channel #1 - Future
J1
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #2 - Future
J2
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #3 – Manifold Pressure Eng. Drive
J3
out*
1-2
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #4 - Entering Process Temperature**
J4
out
1-2
2-3*
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #5 - Temp.\Pressure Monitoring Aux. #1**
J5
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #6 - Temp.\Pressure Monitoring Aux. #2**
J6
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #7 - Temp.\Pressure Monitoring Aux. #3**
J7
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #8 - Temp.\Pressure Monitoring Aux. #4**
J8
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #9 - Temp.\Pressure Monitoring Aux. #5**
J9
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #10 - Temp.\Pressure Monitoring Aux. #6**
J10
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #11 - Temp.\Pressure Monitoring Aux. #7**
J11
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #12 - Temp.\Pressure Monitoring Aux. #8**
J12
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #13 - Temp.\Pressure Monitoring Aux. #9**
J13
out
1-2*
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
Input Channel #14 - Temp\Pressure Monitoring Aux. #10**
Default -Side Load \ Economizer**
J14
in*
out
All other Input
types (0-5 volt, 4-20 mA,
ICTD)
Slide valve potentiometer Input.
J15
out*
1-2
2-3
0-5 volt Input
4-20 mA Input
ICTD Input
J16
in*
out
All other Input
types (0-5 volt, 4-20 mA,
ICTD)
Slide valve potentiometer Input.
Input Channel #15 – Main Oil Injection **
J17
in*
out
All other input types (0-5 volt, 4-20 mA,
ICTD)
Slide valve potentiometer input.
J18
out*
1-2
2-3
0-5 volt input (standard setting)
4-20 mA Input
ICTD input
J19
in*
out
All other input types (0-5 volt, 4-20 mA,
ICTD)
Slide valve potentiometer input.
Input Channel #16 - Kw Monitoring**
J20 J21 J22
0-5 amp CT input out out in
0-5 volt input out out out
4-20 mA input* in out out
ICTD input out In out
* standard setting
** = If applicable
