Frick QUANTUM 3 - Capacity Control Selection

S90-010 M FRICK

QUANTUM™ COMPRESSOR CONTROL PANEL
Page 44 MAINTENANCE
Capacity Control Selection:
Select capacity control (2 maximum)
Suction pressure ______
Process temperature ______
Discharge pressure (air compressor mode) ______
User Selectable mode ______
User Selectable Mode:
Action
Enable Disable Control Channel Serial Communications Timeout
Forward Reverse
Selected Options:
Auxiliary 1&2:
Disable auxiliary 1 auxiliary 2 auxiliary 1 & 2
Power Failure Restart:
Enabled Disabled
Input module capacity control selection (used with PLC to select capacity control mode):
Enabled Disabled
Compressor Sequencing:
Disable Sequence Mode 1 Sequence Mode 2 (Gram) Compressor Interlock
Condenser Control:
Disable Digital Analog Digital & Analog
Suction Pressure Pull Down:
Enabled Disabled
Hot Gas Bypass/SV Setpoint:
Enabled Disabled
Auxiliaries 3-8:
Enabled Disabled
Pumpdown DX Circuit:
Enabled Disabled
Kilowatt Monitor Calibration and Setup:
Enabled Disabled
