FRICK
®
QUANTUM™ COMPRESSOR CONTROL PANEL S90-010 CS (APR 08)
COMMUNICATIONS SETUP Page 17
RETURN OPERATING STATUS Page 4 data: $01D4
$ Start of command sequence.
01 Compressor ID code.
D4 Operating Status – Page 1 command.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Starting
Character
Position
Description of returned data
1 A Acknowledge
2 01 Compressor ID code.
4 Date as 00/00/00
13 Time as hh:mm:ss
23 Remaining Recycle time as mm:ss
30 CS (Checksum followed by Carriage
return, Line feed.)
RETURN Suction Pressure Capacity Control
Mode 1 & 2 setpoints – Page 0: $01s0
$ Start of command sequence.
01 Compressor ID code.
s0 Suction Press. Cap. Control Page 0
command.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Starting
Character
Position
Description of returned data
1 A Acknowledge
2 01 Compressor ID code.
4 Suction Pressure Control Setpoint 1
13 Suction Press. Upper Prop. Band 1
22 Suction Press. Lower Prop. Band 1
31 Suction Press. Upper Dead Band 1
40 Suction Press. Lower Dead Band 1
49 Suction Press. Upper Cycle Time 1
58 Suction Press. Lower Cycle Time 1
67 Suction Press. Auto Start Setpoint 1
76 Suction Press. Auto Stop Setpoint 1
85 Suction Press. Auto Start delay 1
94 Suction Press. Auto Stop delay 1
103 CS (Checksum followed by Carriage
return, Line feed.)
RETURN Suction Pressure Capacity Control
Mode 1 & 2 setpoints – Page 1: $01s1
$ Start of command sequence.
01 Compressor ID code.
S1 Suction Press. Cap. Control Page 1
command.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Starting
Character
Position
Description of returned data
1 A Acknowledge
2 01 Compressor ID code.
4 Suction Pressure Control Setpoint 2
13 Suction Press. Upper Prop. Band 2
22 Suction Press. Lower Prop. Band 2
31 Suction Press. Upper Dead Band 2
40 Suction Press. Lower Dead Band 2
49 Suction Press. Upper Cycle Time 2
58 Suction Press. Lower Cycle Time 2
67 Suction Press. Auto Start Setpoint 2
76 Suction Press. Auto Stop Setpoint 2
85 Suction Press. Auto Start delay 2
94 Suction Press. Auto Stop delay 2
103 CS (Checksum followed by Carriage
return, Line feed.)
RETURN Suction Pressure Capacity Control
Mode 1 & 2 setpoints – Page 2: $01s2
$ Start of command sequence.
01 Compressor ID code.
S2 Suction Press. Cap. Control Page 2
command.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Starting
Character
Position
Description of returned data
1 A Acknowledge
2 01 Compressor ID code.
4 Suction Press. Stop Load 1
13 Suction Press. Force Unload 1
22 Suction Press. Low Alarm 1
31 Suction Press. Low Shutdown 1
40 Suction Press. Low Alarm delay 1
49 Suction Press. Low Shutdown delay 1
58 Suction Press. Stop Load 2
67 Suction Press. Force Unload 2
76 Suction Press. Low Alarm 2
85 Suction Press. Low Shutdown 2
94 Suction Press. Low Alarm delay 2
103 Suction Press. Low Shutdown delay 2
104 CS (Checksum followed by Carriage
return, Line feed.)
