S90-010 CS (APR 08) FRICK
®
QUANTUM™ COMPRESSOR CONTROL PANEL
Page 18 COMMUNICATIONS SETUP
RETURN Process Temperature Capacity Control
Mode 1 & 2 setpoints – Page 0: $01p0
$ Start of command sequence.
01 Compressor ID code.
p0 Process Temperature Cap. Control Page 0
command.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Starting
Character
Position
Description of returned data
1 A Acknowledge
2 01 Compressor ID code.
4 Process Temperature Control 1
13 Process Temperature Upper Prop. Band 1
22 Process Temperature Lower Prop. Band 1
31 Process Temperature Upper Dead Band 1
40 Process Temperature Lower Dead Band 1
49 Process Temperature Upper Cycle Time 1
58 Process Temperature Lower Cycle Time 1
67 Process Temperature Auto Start Setpoint 1
76 Process Temperature Auto Stop Setpoint 1
85 Process Temperature Auto Start delay 1
94 Process Temperature Auto Stop delay 1
103 CS (Checksum followed by Carriage
return, Line feed.)
RETURN Process Temperature Capacity Control
Mode 1 & 2 setpoints – Page 1: $01p1
$ Start of command sequence.
01 Compressor ID code.
p1 Process Temperature Cap. Control Page 1
command.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Starting
Character
Position
Description of returned data
1 A Acknowledge
2 01 Compressor ID code.
4 Process Temperature Control 2
13 Process Temperature Upper Prop. Band 2
22 Process Temperature Lower Prop. Band 2
31 Process Temperature Upper Dead Band 2
40 Process Temperature Lower Dead Band 2
49 Process Temperature Upper Cycle Time 2
58 Process Temperature Lower Cycle Time 2
67 Process Temperature Auto Start Setpoint 2
76 Process Temperature Auto Stop Setpoint 2
85 Process Temperature Auto Start delay 2
94 Process Temperature Auto Stop delay 2
103 CS (Checksum followed by Carriage
return, Line feed.)
RETURN Process Temperature Capacity Control
Mode 1 & 2 setpoints – Page 2: $01p2
$ Start of command sequence.
01 Compressor ID code.
p2 Process Temperature Capacity Control
Page 2 command.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Starting
Character
Position
Description of returned data
1 A Acknowledge
2 01 Compressor ID code.
4 Process Temperature Stop Load 1
13 Process Temperature Force Unload 1
22 Process Temperature Low Alarm 1
31 Process Temperature Low Shutdown 1
40 Process Temperature Low Alarm delay 1
49 Process Temp. Low Shutdown delay 1
58 Process Temperature Stop Load 2
67 Process Temperature Force Unload 2
76 Process Temperature Low Alarm 2
85 Process Temperature Low Shutdown 2
94 Process Temperature Low Alarm Delay 2
103 Process Temp. Low Shutdown Delay 2
112 CS (Checksum followed by Carriage
return, Line feed.)
RETURN Process Temperature Capacity Control
Mode 1 & 2 setpoints – Page 3: $01p3
$ Start of command sequence.
01 Compressor ID code.
p3 Process Temperature Cap. Control Page 3
command.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Starting
Character
Position
Description of returned data
1 A Acknowledge
2 01 Compressor ID code.
4 Process Temp. Low Suction Stop Load 1
13 Process Temp. Low Suction Force Unload 1
22 Process Temp. Low Suction Alarm 1
31 Process Temp. Low Suction Shutdown 1
40 Process Temp. Low Suction Alarm delay 1
49 Process Temp. Low Suction Shutdown Dly 1
58 Process Temp. Low Suction Stop Load 2
67 Process Temp. Low Suction Force Unload 2
76 Process Temp. Low Suction Alarm 2
85 Process Temp. Low Suction Shutdown 2
94 Process Temp. Low Suction Alarm Delay 2
103 Process Temp. Low Suction Shutdown Dly 2
112 CS (Checksum followed by Carriage return,
Line feed.)
