FRICK
®
QUANTUM™ COMPRESSOR CONTROL PANEL S90-010 CS (APR 08)
COMMUNICATIONS SETUP Page 49
DIGITAL BOARD 1 (READ ONLY):
Frick
®
Address
AB
Address
Modbus
Address
Description of Data
Module
Type
Value Codes
0 N50:0 40001 Compressor Start Output
0 = Off
1 = On
1 N50:1 40002 Compressor Auxiliary Input
0 = Off
1 = On
2 N50:2 40003 Oil Pump #1 Start/Run Output
0 = Off
1 = On
3 N50:3 40004 Oil Pump #1 Auxiliary Input
0 = Off
1 = On
4 N50:4 40005 Slide Valve Load Output
0 = Off
1 = On
2 = Off
5 N50:5 40006 Slide Valve Unload Output
0 = Off
1 = On
2 = Off
6 N50:6 40007 Slide Stop Increase Output
0 = Off
1 = On
2 = Off
7 N50:7 40008 Slide Stop Decrease Output
0 = Off
1 = On
2 = Off
8 N50:8 40009 Liquid Injection Output
0 = Off
1 = On
9 N50:9 40010 Hi-Vi Liquid Injection Output
0 = Off
1 = On
10 N50:10 40011 Economizer Output
0 = Off
1 = On
11 N50:11 40012 Balance Piston Output
0 = Off
1 = On
12 N50:12 40013 Oil Level Input
0 = Off
1 = On
13 N50:13 40014 High Liquid Level from System Input
0 = Off
1 = On
14 N50:14 40015 Enclosure Heater Output
0 = Off
1 = On
15 N50:15 40016 Hot Gas Bypass Output
0 = Off
1 = On
16 N50:16 40017 Aux. #1 Input
0 = Off
1 = On
17 N50:17 40018 Aux. #2 Input
0 = Off
1 = On
18 N50:18 40019 Process Mode Select Input
0 = 1
st
Mode
1 = 2
nd
Mode
19 N50:19 40020 Capacity Control Setpoint #2 Input
0 = Mode 1
1 = Mode 2
20 N50:20 40021 Oil Heater Output
0 = Off
1 = On
21 N50:21 40022 Alarm Output
0 = None
1 = Alarm
22 N50:22 40023 Shutdown Output
0 = Shutdown
1 = None
23 N50:23 40024 Power Assist Output
0 = Off
1 = On
