Frick QUANTUM Series - Page 50

S90-010 CS (APR 08) FRICK
®
QUANTUM™ COMPRESSOR CONTROL PANEL
Page 50 COMMUNICATIONS SETUP
DIGITAL BOARD 2 (READ ONLY):
Frick
®
Address
AB
Address
Modbus
Address
Description of Data
Module
Type
Value Codes
24 N50:24 40025 Ready-To-Run Output
0 = Off
1 = On
25 N50:25 40026 Remote Enabled Output
0 = Off
1 = On
26 N50:26 40027 Remote Start/Run/Stop Input
0 = Stop
1 = Start/Run
27 N50:27 40028 Remote Load Input
0 = Off
1 = On
28 N50:28 40029 Remote Unload Input
0 = Off
1 = On
29 N50:29 40030 In Recycle Delay Output
0 = Off
1 = On
30 N50:30 40031 Slide Valve Setpoint #1 Output
0 = Off
1 = On
31 N50:31 40032 Slide Valve Setpoint #2 Output
0 = Off
1 = On
32 N50:32 40033 Aux. #3 Input
0 = Off
1 = On
33 N50:33 40034 Aux. #4 Input
0 = Off
1 = On
34 N50:34 40035 Aux. #5 Input
0 = Off
1 = On
35 N50:35 40036 Aux. #6 Input
0 = Off
1 = On
36 N50:36 40037 Aux. #7 Input
0 = Off
1 = On
37 N50:37 40038 Aux. #8 Input
0 = Off
1 = On
38 N50:38 40039 Oil Pump #2 Start Output
0 = Off
1 = On
39 N50:39 40040 Oil Pump #2 Auxiliary Input
0 = Off
1 = On
40 N50:40 40041 Permissive Start Input
0 = Off
1 = On
41 N50:41 40042 Main Oil Injection Discharge Temp. Output
0 = Off
1 = On
42 N50:42 40043 Dx Circuit #1 Output
0 = 1
st
Mode
1 = 2
nd
Mode
43 N50:43 40044 Dx Circuit #2 Output
0 = Mode 1
1 = Mode 2
44 N50:44 40045 Condenser Control #1 Output
0 = Off
1 = On
45 N50:45 40046 Condenser Control #2 Output
0 = None
1 = Alarm
46 N50:46 40047 Condenser Control #3 Output
0 = None
1 = Shutdown
47 N50:47 40048 Condenser Control #4 Output
0 = Off
1 = On
