FRICK
®
QUANTUM™ COMPRESSOR CONTROL PANEL S90-010 CS (APR 08)
COMMUNICATIONS SETUP Page 51
CALCULATED/STATUS (READ ONLY):
Frick
®
Address
AB
Address
Modbus
Address
Description of Data Value Codes
97 N10:1 40098 Motor Full Load Amps %
99 N10:3 40100 Filter Differential
101 N10:5 40102 Motor/Engine Drive Type
0 = Electric - Constant
1 = Electric - VFD
2 = Engine
3 = Turbine
102 N10:6 40103 Process Setpoint (Actual)
103 N10:7 40104 Process Control Mode
0 = Suction Pressure Control Mode 1
1 = Suction Pressure Control Mode 2
2 = Process Temperature Control Mode 1
3 = Process Temperature Control Mode 2
4 = Discharge Pressure Control Mode 1
5 = Discharge Pressure Control Mode 2
6 = Discharge Temperature Control Mode 1
7 = Discharge Temperature Control Mode 2
105 N10:9 40106 Compressor Mode
0 = Manual
1 = Automatic cycling
2 = Remote Start
106 N10:10 40107 Alarm Status
0 = Off
1 = On
107 N10:11 40108 Shutdown Status
0 = Off
1 = On
108 N10:12 40109 Language
0 = English
1 = Danish
2 = German
3 = Spanish
4 = French
109 N10:13 40110 Temperature
0 = Fahrenheit
1 = Celsius
110 N10:14 40111 Pressure
0 = PSIA
1 = PSIG
2 = BarA
3 = KPAA
4 = Bar
111 N10:15 40112 Compressor Running Status
0 = Off
1 = Running
2 = Starting
113 N10:17 40114 Compressor Model
0 = RWBII
1 = RXB
2 = RXF
3 = Other Compressor Manufacturer
4 = GSV II
5 = RDB 4-Step
6 = RDB 3-Step
7 = GST
8 = Var. VI
9 = GSB
10= Gram Other
11 = SC
12 = YLC
13 = YORK-S7
14 = RWF
15 = YORK-S5
16 = Recip - 0
17 = Recip - 1
18 = Recip - 2
19 = Recip - 3
