Page 52 COMMUNICATIONS SETUP
CALCULATED/STATUS (READ ONLY):
Frick
®
Address
AB
Address
Modbus
Address
Description of Data Value Codes
114 N10:18 40115 Pump Operation
0 = No Pump
1 = Prelube
2 = Cycling
3 = FullTime
4 = Shaft Driven with Aux. Pre-Lube
5 = Shaft Driven No Pump
6 = Demand
115 N10:19 40116 Differential Pressure
116 N10:20 40117 Slide Valve Mode
0 = Manual
1 = Automatic
2 = Remote
4 = Remote Control Setpoint
117 N10:21 40118 Slide Stop Mode
0 = Manual
1 = Automatic
118 N10:22 40119 Stop/Force Unload Status
0 = Not Stopping or Forcing Unload
1 = Stop Load - High Motor Amps
2 = Stop Load - High Discharge Pressure
3 = Stop Load - High Discharge Temperature
4 = Stop Load - Low Suction Pressure
5 = Stop Load - High Suction Pressure
6 = Stop Load - Low Process Temperature
7 = Force Unload - High Motor Amps
8 = Force Unload - High Discharge Pressure
9 = Force Unload - High Discharge Temperature
10 = Force Unload - Low Suction Pressure
11 = Force Unload - High Suction Pressure
12 = Force Unload - Low Process Temperature
13 = Stop Load - Low Oil Flow
14 = Force Unload - Low Oil Flow
15 = Force Unload - VI OverRide
16 = At Maximum Load
17 = Stop Load - Separator Velocity
18 = Force Unload - Separator Velocity
19 = Force Unload - Stopping
20 = Stop Load - Low RPM
21 = Force Unload - Low RPM
22 = Stop Load - High Manifold Pressure
23 = Force Unload - High Manifold Pressure
24 = Warm-up Load Inhibit
25 = Slide Valve Pulldown
26 = Stop Load - VariSpeed High Baseplate
27 = Force Unload - VariSpeed High Baseplate
28 = Stop Load - VariSpeed High Heatsink
29 = Force Unload - VariSpeed High Heatsink
30 = Stop Load - VariSpeed High Ambient
31 = Force Unload - VariSpeed High Ambient
32 = Stop Load - VariSpeed HF High Baseplate
33 = Force Unload - VariSpeed HF High Baseplt
119 N10:23 40120 Calculated Slide Valve Position
121 N10:25 40122 Recycle delay time in minutes
122 N10:26 40123 Oil Pump Mode
0 = Manual
1 = Automatic
123 N10:27 40124 Process Variable
Actual Reading of current capacity control
variable
124 N10:28 40125 Capacity Control Mode
0 = Keypad
1 = Autocycle
2 = Remote
3 = Remote I/O
4 = Remote Communications
5 = Schedule
