QUANTUM™ COMPRESSOR CONTROL PANEL S90-010 CS (APR 08)
COMMUNICATIONS SETUP Page 53
ANALOG DATA VALUES (READ ONLY):
Frick
®
Address
AB
Address
Modbus
Address
Description of Data
128 N10:32 40129 Suction Temperature
129 N10:33 40130 Discharge Temperature
130 N10:34 40131 Oil Temperature
131 N10:35 40132 Oil Separator Temperature
132 N10:36 40133 Leaving Process Temperature
133 N10:37 40134 Oil Pressure
134 N10:38 40135 True Oil Filter Pressure
135 N10:39 40136 Discharge Pressure
136 N10:40 40137 Suction Pressure
137 N10:41 40138 Balance Piston Pressure
138 N10:42 40139 System Discharge Pressure
142 N10:46 40143 Slide Stop Position
143 N10:47 40144 Motor Current
146 N10:50 40147 Manifold Pressure
147 N10:51 40148 Entering Process Temperature
148 N10:52 40149 User-Defined Pressure/Temperature # 1 Monitor only
149 N10:53 40150 User-Defined Pressure/Temperature # 2 Monitor only
150 N10:54 40151 User-Defined Pressure/Temperature # 3 Monitor only
151 N10:55 40152 User-Defined Pressure/Temperature # 4 Monitor only
152 N10:56 40153 User-Defined Pressure/Temperature # 5 Monitor only
153 N10:57 40154 User-Defined Pressure/Temperature # 6 Monitor only
154 N10:58 40155 User-Defined Pressure/Temperature # 7 Monitor only
155 N10:59 40156 User-Defined Pressure/Temperature # 8 Monitor only
156 N10:60 40157 User-Defined Pressure/Temperature # 9 Monitor only
157 N10:61 40158 User-Defined Pressure/Temperature # 10 or Side Load Economizer
158 N10:62 40159 Oil Injection Pressure
159 N10:63 40160 KW Monitor
STARTER PANEL I/O (READ ONLY):
Frick
®
Address
AB
Address
Modbus
Address
Description of Data Value Codes
192 N10:96 40193 was DBS configured
193 N10:97 40194 Average Current
194 N10:98 40195 Elapsed Run Time Hrs
195 N10:99 40196 Starter Alarms
0 = No alarm
3 = Current Unbalance
5 = RTD Temperature)
196 N10:100 40197 Starter Trips
0 = No trip
1 = Short Circuit
2 = Thermal Overload
3 = Shorted SCR
4 = Phase Loss
5 = Phase Reversal
6 = Jam
7 = Heatsink Overtemperature
8 = RTD Overtemperature
197 N10:101 40198 Current Phase A
198 N10:102 40199 Current Phase B
199 N10:103 40200 Current Phase C
200 N10:104 40201 Heatsink Temperature
201 N10:105 40202 RTD Temperature
202 N10:106 40203 Thermal Capacity
203 N10:107 40204 Time till Start
204 N10:108 40205 Full Load Amps
205 N10:109 40206 Constant Current Level
206 N10:110 40207 Ramp Time
0 = Constant Current
1 = Step Ramp
207 N10:111 40208 Thermal Overload Status
208 N10:112 40209 Constant Current/Step Ramp Mode
0 = Inline
1=Delta
