S90-010 CS (APR 08) FRICK
®
QUANTUM™ COMPRESSOR CONTROL PANEL
Page 54 COMMUNICATIONS SETUP
STARTER PANEL I/O (READ ONLY): Continued
Frick
®
Address
AB
Address
Modbus
Address
Description of Data Value Codes
209 N10:113 40210 Starter Wiring
210 N10:114 40211 Starter Size
0 = A1
1 = A2
2 = B1
3 = B2
4 = B3
5 = B4
6 = C1
7 = C2
8 = C3
9 = D1
10 = D2
11 = D3
12 = E1
13 = E2
211 N10:115 40212 DBS Version
212 N10:116 40213 Bypass Time
213 N10:117 40214 Elapsed Run Time Min
207 N10:111 40208 Thermal Overload Status
EXTRA PORT (READ ONLY):
Frick
®
Address
AB
Address
Modbus
Address
Description of Data
223 N10:127 40224 Board Temperature
ANALOG OUTPUTS BOARD #1 (READ ONLY):
Frick
®
Address
AB
Address
Modbus
Address
Description of Data
223 N10:127 40224 Board Temperature
241 N10:145 40242 PID/Programmable
242 N10:146 40243 PID/Programmable
243 N10:147 40244 Slide Valve Position
244 N10:148 40245 Remote Control
ANALOG OUTPUTS BOARD #2 (READ ONLY):
Frick
®
Address
AB
Address
Modbus
Address
Description of Data
245 N10:149 40246 PID/Programmable
246 N10:150 40247 PID/Programmable
247 N10:151 40248 Variable Speed Drive
248 N10:152 40249 Condenser Analog Output
