Frick QUANTUM Series - Page 55

FRICK
®
QUANTUM™ COMPRESSOR CONTROL PANEL S90-010 CS (APR 08)
COMMUNICATIONS SETUP Page 55
SETTINGS:
Frick
®
Address
AB
Address
Modbus
Address
Read
Only
Description of Data
257 N15:0 40258 X Pro
g
ram Version ###.## x100
259 N15:2 40260 Dischar
g
e Tem
p
erature Control Point 1
260 N15:3 40261 Dischar
g
e Tem
p
erature U
pp
er Pro
p
ortional Band 1
261 N15:4 40262 Dischar
g
e Tem
p
erature Lower Pro
p
ortional Band 1
262 N15:5 40263 Dischar
g
e Tem
p
erature U
pp
er Dead Band 1
263 N15:6 40264 Dischar
g
e Tem
p
erature Lower Dead Band 1
264 N15:7 40265 Dischar
g
e Tem
p
erature Pulse Period 1
265 N15:8 40266 Process Tem
p
erature Control Point1
266 N15:9 40267 Process Tem
p
erature U
pp
er Pro
p
ortional Band 1
267 N15:10 40268 Process Tem
p
erature Lower Pro
p
ortional Band 1
268 N15:11 40269 Process Tem
p
erature U
pp
er Dead Band 1
269 N15:12 40270 Process Tem
p
erature Lower Dead Band 1
270 N15:13 40271 Process Tem
p
erature Mode 1 Hi
g
h C
y
cle Time
271 N15:14 40272 Process Tem
p
erature Control Point 2
272 N15:15 40273 Process Tem
p
erature U
pp
er Pro
p
ortional Band 2
273 N15:16 40274 Process Tem
p
erature Lower Pro
p
ortional Band 2
274 N15:17 40275 Process Tem
p
erature U
pp
er Dead Band 2
275 N15:18 40276 Process Tem
p
erature Lower Dead Band 2
276 N15:19 40277 Process Tem
p
erature Mode 2 Hi
g
h C
y
cle Time
277 N15:20 40278 Suction Pressure Control Point 1
278 N15:21 40279 Suction Pressure U
pp
er Pro
p
ortional Band 1
279 N15:22 40280 Suction Pressure Lower Pro
p
ortional Band 1
280 N15:23 40281 Suction Pressure U
pp
er Dead Band 1
281 N15:24 40282 Suction Pressure Lower Dead Band 1
282 N15:25 40283 Dischar
g
e Pressure Control Point 2
283 N15:26 40284 Suction Pressure Mode 1 Hi
g
h C
y
cle Time
284 N15:27 40285 Suction Pressure Control Point 2
285 N15:28 40286 Suction Pressure U
pp
er Pro
p
ortional Band 2
286 N15:29 40287 Suction Pressure Lower Pro
p
ortional Band 2
287 N15:30 40288 Suction Pressure U
pp
er Dead Band 2
288 N15:31 40289 Suction Pressure Lower Dead Band 2
289 N15:32 40290 Suction Pressure Mode 2 Hi
g
h C
y
cle Time
290 N15:33 40291 Suction Pressure Mode 2 Low C
y
cle Time
291 N15:34 40292 Process Tem
p
erature Mode 1 Low C
y
cle Time
292 N15:35 40293 Process Tem
p
erature Mode 2 Low C
y
cle Time
293 N15:36 40294 Slide Valve Start
294 N15:37 40295 Motor Load Control Sto
p
Load
295 N15:38 40296 Motor Load Control Force Unload
296 N15:39 40297 X Com-1
297 N15:40 40298 X Com-2
298 N15:41 40299 X I/O & Analo
g
Board Comm. Port
299 N15:42 40300 Dischar
g
e Pressure Mode 2 Low Alarm
300 N15:43 40301 Dischar
g
e Pressure Mode 2 Low Shutdown
301 N15:44 40302 Suction Pressure Mode 1 Low Alarm
302 N15:45 40303 Suction Pressure Mode 1 Low Shutdown
303 N15:46 40304 Dischar
g
e Pressure Mode 1 Low Alarm
304 N15:47 40305 Dischar
g
e Pressure Mode 1 Low Shutdown
305 N15:48 40306 Suction Pressure Mode 2 Low Alarm
306 N15:49 40307 Suction Pressure Mode 2 Low Shutdown
307 N15:50 40308 Dischar
g
e Pressure Mode 2 Low Alarm Dela
y
308 N15:51 40309 Dischar
g
e Pressure Mode 2 Low Shutdown Dela
y
309 N15:52 40310 Suction Pressure Mode 1 Low Alarm Dela
y
310 N15:53 40311 Suction Pressure Mode 1 Low Shutdown Dela
y
311 N15:54 40312 Dischar
g
e Pressure Mode 1 Low Alarm Dela
y
312 N15:55 40313 Dischar
g
e Pressure Mode 1 Low Shutdown Dela
y
313 N15:56 40314 Suction Pressure Mode 2 Low Alarm Dela
y
314 N15:57 40315 Suction Pressure Mode 2 Low Shutdown Dela
y
315 N15:58 40316 X Refri
g
erant
316 N15:59 40317 Sales Order Number
317 N15:60 40318 Dischar
g
e Pressure Control Point 1
318 N15:61 40319 Dischar
g
e Pressure U
pp
er Pro
p
ortional Band 1
