Frick RWB II - RECOMMENDED SPARE PARTS - CURRENT DESIGN

RWB II ROTARY SCREW COMPRESSOR UNITS
MAINTENANCE
S70-200 IOM
Page 55
QUANTUM
™
CONTROL:
Assembly, VGA Display, Phillips (Display only, 649C1078H01) 1 ALL 640C0052G01
Assembly, Digital Board #1 1 ALL 640C0024G01
Assembly, Digital Board #2 1 ALL 640C0024G02
Assembly, Analog Board #1 1 ALL 640C0026G01
Assembly, Analog Board #2 1 ALL 640C0026G02
Inverter, Sharp & Phillips 1 ALL 333Q0001582
Power Supply 1 ALL 640C0022G01
Switch, Power 1 ALL 333Q0001194
Block, Contact, Power Switch 1 ALL 333Q0001195
Circuit Breaker, 10 Amp 1 ALL 649A0883H10
Circuit Breaker, 16 Amp 1 ALL 649A0883H16
Cable, Key Pad 1 ALL 640B0031H01
Cable, LCD Display, Quantum™ 4 1 ALL 649D4824H01
Cable Harness, Power 1 ALL 640B0038H01
Keypad, Overlay 1 ALL 640D0060H01
Circuit Board, Main (Arcom), Quantum™ 4 1 ALL 649C1091G01
Module, Output, 280V (For 115/230V) 2 ALL 111Q0281061
Module, Input, 90-140V (For 115V) 1 ALL 333Q0000116
Fuse, 5 Amp, 250V, I/O Board 4 ALL 333Q0001326
Relay, 3PDT, 115V 1 ALL 333Q0000206
UNIT:
Temperature Probe (TE-1—4) 1 ALL 640A0035H01
Transducer, Pressure, 0—200 PSIA (Quantum only) 1 ALL 913A0110H01
Transducer, Pressure, 0—500 PSIA (Quantum only) 1 ALL 913A0110H02
Potentiometer, Slide Stop 1 ALL 111Q0041148
Kit, Potentiometer, Slide Valve 1 ALL 534D0523G02
Valve, Solenoid, Slide Stop/Slide Valve, Vickers 1 ALL 951A0056H39
Coil For 951A0056H39 Above 1 ALL 951A0056H40
Heater, Oil, 500W, 120V 1 ALL 913A0047H01
Heater, Oil, 500W, 240V 1 ALL 913A0047H03
Filter, Coalescing, Standard A/R ALL 531B0019H01
Filter, Coalescing, Convoluted A/R ALL 531B0065H01
Gasket, Manway For Coalescer 1 60—76 531A0105H03
Gasket, Manway For Coalescer 1 100—856 531A0105H04
Element, Oil Filter, SuperFilter
™
(Required for 1-2-3 Warranty) A/R ALL 531A0218H01
Gasket, End Cover for 531A0218H01 Above A/R ALL 959A0082H01
Gasket, Clamping Plate for 531A0218H01 Above A/R ALL 959A0053H01
Shaft Seal Replacement Kit* 1 60—76 534M0163G01
Shaft Seal Replacement Kit* 1 100—134 534M0163G02
Shaft Seal Replacement Kit* 1 177—270 534M0163G03
Shaft Seal Replacement Kit* 1 316—480 534M0163G04
Shaft Seal Replacement Kit 1 496—856 534M0163G05
Note: This list is based on one unit. When stocking for more than one unit, the quantity should be adjusted
RECOMMENDED SPARE PARTS - CURRENT DE SIGN
ITEM DESCRIPTION MODELSQTY. ITEM NUMBER
