Frick RWB II - Vibration Data Sheet

RWB II PLUS ROTARY SCREW COMPRESSOR UNITS
FORMS
S70-200 IOM
Page 54
Soft Foot Soft Foot
Soft Foot Soft Foot
Motor Inboard
Compressor Inboard Compressor Inboard (Coupled End)
(Coupling End) (Coupling End Male) Horizontal . IPS Overall
Vertical Direction Axial Direction Vertical . IPS Overall
. IPS Overall . IPS Overall Axial . IPS Overall
Motor Outboard
Compressor Outboard Compressor Inboard (Noncoupled End)
(Nondrive End) (Coupling End Female) Horizontal . IPS Overall
Vertical Direction Axial Direction Vertical . IPS Overall
. IPS Overall . IPS Overall Axial . IPS Overall
Date: ______________________________________ Sales Order Number: _____________________________
End User: ___________________________________ Installing Contractor: _____________________________
Address: ______________________________________ Service Technician: ______________________________
Equipment ID (As in Microlog): __________________
Compressor Serial Number: _______________________
Unit Serial Number: ______________________________
National Board Number: __________________________
Running Hours: _________________________________
Manufacturer and Size of Coupling: _________________
Motor Manufacturer: RAM _________________________
Motor Serial Number: ____________________________
RPM: ______ Frame Size: _________ H.P. ________
Refrigerant:
Ambient Room Temperature: __________°F
Operating Conditions:
VIBRATION DATA SHEET
Final Hot Alignment
SUCTION DISCHARGE OIL SEPARATOR Slide Valve Position %
Press # Press # Press # Temp °F V.I. Ratio
Temp °F Temp °F Temp °F F.L.A. %
Total Thickness of Shims Added
