XJF ROTARY SCREW COMPRESSOR
INSTALLATION
INSTALLATION
DESIGN LIMITS
General information for all of the models is provided below.
Please see CoolWare to determine the limits for a specic
application.
XJF compressors are primarily designed for connecting to
an electric drive motor using a tunnel mount. If the appli-
cation requires it, the compressor can also be driven with
a foot-mounted motor. The tunnel mount ensures proper
alignment of the compressor and motor so that the shaft
seal and coupling will operate properly. The rotor and
bearing design set limitations must not be exceeded (See
Frick Selection Program, CoolWare). Pressure and tem-
perature limits are shown in Frick publication 070.410-
SED. Refer to Johnson Controls-Frick Compressor Control
Panel instruction 090.040-O for additional information on
setpoint limits.
OUTLINE DIMENSIONS
Drawings for reference only can be found on the following
pages. Complete dimensions and access connections can
be found on the outline drawings.
XJF 95 DWG# 534E0458
XJF 120 DWG# 534E0299
XJF 151 DWG# 534E0539
If you do not have these drawings, please request any you
require by contacting Johnson Controls-Frick sales.
The NOTES below apply to the Dimensions and
Compressor Port Location drawings on the following
pages.
1. A metric rectangular parallel key is supplied with each
XJF 95 and 120 compressor. Metric key conforms to din
6885A specication. A standard square parallel key is
supplied with each XJF 151 compressor.
2. Standard voltage for solenoid coils is 110 VAC unless
otherwise specied. Other voltages are available upon
request.
3. Rotation of compressor jackshaft is clockwise when
viewing the shaft end.
4. Solenoid control valves for Volume Ratio Slide Stop (SS)
are included in delivery, including solenoids.
Solenoid control valves for Capacity Control Slide Valve
(SV) are NOT included in delivery. Internal piping is
included. A solenoid control valve kit with gasket can be
ordered or specied separately on the sales order. The
solenoid valve is a standard type D03/CETOP with O-rings
suitable for application (either HNBR or Viton)
5. Motor support is not provided as part of the bare
compressor. When required a motor support kit shall be
specied on the sales order separately.
Approximate mass:
XJF 95: 600 lbm (272 kg)
XJF 120: 845 lbm (383 kg)
XJF 151: 1210 lbm (550 kg)
