101 PB
PARTS CATALOG
230V Outdoor Unit 9k
Figure 908
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
16 67400760 1822371 ‑ Compressor connect
wire
FPHSR09A3A 1
17 67400761 1824870 ‑ valve seat FPHSR09A3A 1
18 67400279 1838379 ‑ Capillary assembly FPHSR09A3A 1
19 67400280 1258653 ‑ 1/4 2‑way valve FPHSR09A3A 1
20 67400281 1407169 ‑ 3/8 3‑way valve FPHSR09A3A 1
21 67400762 1855206 ‑ right side board FPHSR09A3A 1
22 67400763 1854033 ‑ wiring distribution
cover assy
FPHSR09A3A 1
23 67400202 1854034 ‑ xed board FPHSR09A3A 1
24 67401230 1894523‑ electric box FPHSR09A3A 1
25 67400766 1843011 ‑ connecting board FPHSR09A3A 1
26 67400282 1854383 ‑ Wire terminal board FPHSR09A3A 1
27 67401231 2100183 ‑ Outdoor Main Control
Board Component
FPHSR09A3A 1
28 67400787 1894526 ‑ electric box cover FPHSR09A3A 1
29 67400291 1472663 ‑ Temperature sensor FPHSR09A3A 1
30 67400289 1472664 ‑ Temperature sensor FPHSR09A3A 1
31 67400210 1831029 ‑ Temperature sensor FPHSR09A3A 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
To Next Page
