SPECIFICATIONS
Product Specications 9k and 12k
Model No. Units FPHW091/A FPHW121/A FPHW093/A FRHW093/A FPHW123/A FRHW123/A
INDOOR MODEL FPHSW09A1A,
FPHSW09A1B/B
FPHSW12A1A,
FPHSW12A1B/B
FPHFW09A3A,
FPHFW09A3B/B
FRHSW09A3A,
FRHSW09A3B/B
FPHFW12A3A,
FPHFW12A3B/B
FRHSW12A3A,
FRHSW12A3B/B
OUTDOOR MODEL FPHSR09A1A FPHSR12A1A FPHSR09A3A FRHSR09A3A FPHSR12A3A FRHSR12A3A
SPECIFICATIONS
C A P A C I T Y C O O L I N G ( R AT E D ) Btu 9000 12000 9000 9000 12000 12000
C A PA C I T Y C O O L I N G M I N ‑ M A X Btu 3600‑10000 4000‑13500 3600‑10000 3600‑10000 4000‑13500 4000‑13500
COOLING AMPS 6.3 8.3 2.9 10500 4.3 13000
HEATING AMPS 7.0 9.7 3.1 6500 5.0 8000
SENSIBLE HEAT RATIO 76% 77% 76% 3600‑10500 77% 4000‑14000
CAPACITY HEATING (RATED) @ 47°F Btu 9500 13000 9500 2.3 13000 4.6
C A PA C I T Y H E A T I N G M I N ‑ M A X Btu 3600‑10500 4000‑14000 3600‑10500 3.4 4000‑14000 4.8
CAPACITY HEATING (RATED) @ 17°F Btu 5000 7500 5000 76% 7500 77%
COP 3.56 3.46 3.88 28 3.42 25
HSPF 10.00 10.50 10.70 16.1 10.50 15.4
SEER 19.5 22.0 22.5 12.5 22.0 12
EER 12.8 13.0 13.7 Yes 13.0 Yes
MOISTURE REMOVAL Pts/h 1.9 2.5 1.9 1.9 2.5 2.5
A I R F L O W ( H I G H / M E D / L O W / Q U I E T ) CFM 424/382/323/247 424/382/323/247 424/382/323/247 416/384/355/279 424/382/323/247 598/536/446/345
SOUND RATING ‑ INDOOR (HIGH/
MED/LOW/QUIET)
dB‑A 39/32/29/26 39/32/29/26 39/32/29/26 39/34/31 39/32/29/26 45/41/39
S O U N D R A T I N G ‑ O U T D O O R dB‑A 53 53 53 55 53 55
O P E R A T I N G R A N G E ( H E AT I N G ) °F (‑4° – 75°) (‑4° – 75°) (‑4° – 75°) 0˚‑115˚ (‑4° – 75°) 0˚‑115˚
O P E R AT I N G R A N G E ( C O O L I N G ) °F (5° – 115°) (5° – 115°) (5° – 115°) ‑13˚‑75˚ (5° – 115°) ‑13˚‑75˚
ELECTRICAL DATA
POWER SOURCE V/Hz/
Phase
115V~,60Hz,1P 115V~,60Hz,1P 230V~,208V~,
60Hz,1P
230V~,208V~,
60Hz,1P
230V~,208V~,
60Hz,1P
230V~,208V~,
60Hz,1P
MIN. AMPACITY A 13.5 16.5 10 10A 10 12A
COOL I N G WATTS W 700 950 655 559 960 779
HEATING WATTS W 780 1100 720 905 1110 856
M A X . T D F U S E / B R E A K E R A 20 25 15 15A 15 15A
POWER AND COMMUNICATION
CABLE
Type 4 x 14AWG
600V THHN
4 x 14AWG
600V THHN
4 x 14AWG
600V THHN
4 x 14AWG
600V THHN
4 x 14AWG
600V THHN
4 x 14AWG
600V THHN
REFRIGERATION SYSTEM
REFRIGERANT R410a R410a R410a R410a R410a R410a
COMPRESSOR TYPE Rotary Rotary Rotary Rotary Rotary Rotary
CONNECTIONS Flare Flare Flare Flare Flare Flare
LIQU I D L I N E O . D . in 1/4 1/4 1/4 1/4 1/4 1/4
SUCTION LI N E O.D. in 3/8 3/8 3/8 3/8 3/8 3/8
REFRIGERANT CHARGE oz 33.5 40.9 33.5 25 40.9 25
FACTO R Y P RE CH AR GE ft. 25 25 25 38.8 25 45.9
M I N . / M A X . L I N E L E N G T H ft 9.8‑50 9.8‑50 9.8‑50 10‑66 9.8‑50 10‑66
M A X . H E I G H T D I F F E R E N C E ft 33 33 33 33 33 33
DIMENSIONS & WEIGHT
INDOOR UNIT
W x H x D in 33 7/8 x 11 3/16
x 8 1/2
33 7/8 x 11 3/16
x 8 1/2
33 7/8 x 11 3/16
x 8 1/2
33 7/8 x 11 3/16
x 8 1/2
33 7/8 x 11 3/16
x 8 1/2
38 1/8 X 13 1/8 X
9 15/16
NET WEIGHT lbs 20 20 20 22 20 28.5
OUTDOOR UNIT
W x H x D in 28 1/8 x 19 x 9 7/16 31 7/8 x 23 x 11 28 1/8 x19 x 9 7/16 31 7/8 x 23 x 11 31 7/8 x 23 x 11 31 7/8 x 23 x 11
