103 PB
PARTS CATALOG
230V Outdoor Unit 12k
Figure 909
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
17 67400271 1854557 ‑ Capillary assembly FPHSR12A3A 1
18 67400272 1844583 ‑ 1/4 2‑way valve FPHSR12A3A 1
19 67400199 1335015 ‑ 3/8 3‑way valve FPHSR12A3A 1
20 67400200 1846084 ‑ right side board FPHSR12A3A 1
21 67400201 1854040 ‑ wiring distribution
cover assy
FPHSR12A3A 1
22 67400202 1854034 ‑ xed board FPHSR12A3A 1
23 67400784 1937153 ‑ connecting board FPHSR12A3A 1
24 67400785 1852125 ‑ Wire terminal board FPHSR12A3A 1
25 67400781 1951957 ‑ electric box FPHSR12A3A 1
26 67400294 1985663 ‑ Outdoor Main Control
Board Component
FPHSR12A3A 1
27 67400787 1894526 ‑ electric box cover FPHSR12A3A 1
28 67400291 1472663 ‑ Temperature sensor FPHSR12A3A 1
29 67400301 1511780 ‑ Temperature sensor FPHSR12A3A 1
30 67400210 1831029 ‑ Temperature sensor FPHSR12A3A 1
31 67400211 1546721 ‑ sensor mounting plate FPHSR12A3A 1
‑32 67400789 2008361 ‑ Tube type electric
heater
FPHSR12A3A 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
