115 PB
Figure 915
PARTS CATALOG
230v Outdoor Unit 9K HIGH SEER
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
15 67400195 1907920 COMPRESSOR FRHSR09A3A 1
16 67400196 1847142 STRONG ELECTRICITY
CONNECT WIRE
FRHSR09A3A 1
17 67400197 1864846 ELECTRONIC
EXPANSION VALVE ASSEMBLY
FRHSR09A3A 1
18 67400198 1405371 1/4 2‑WAY VALVE FRHSR09A3A 1
19 67400199 1335015 3/8 3‑WAY VALVE FRHSR09A3A 1
20 67400200 1846084 RIGHT SIDE BOARD FRHSR09A3A 1
21 67400201 1854040 WIRING DISTRIBUTION
COVER ASSY
FRHSR09A3A 1
22 67400202 1854034 FIXED BOARD FRHSR09A3A 1
23 67400203 1842392 CONNECTING BOARD FRHSR09A3A 1
24 67400204 1852124 WIRE TERMINAL BOARD FRHSR09A3A 1
25 67400205 1841985 ELECTRIC BOX FRHSR09A3A 1
26 67401223 2100175 CONTROLLER
COMPONENT
FRHSR09A3A 1
27 67400207 1546706 ELECTRIC BOX COVER FRHSR09A3A 1
28 67400208 1822633 TEMPERATURE SENSOR FRHSR09A3A 1
29 67400209 1822634 TEMPERATURE SENSOR FRHSR09A3A 1
30 67400210 1831029 TEMPERATURE SENSOR FRHSR09A3A 1
31 67400211 1546721 SENSOR MOUNTING
PLATE
FRHSR09A3A 1
‑32 67401132 1854766 ‑ Tube Electric Heater FRHSR09A3A 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
