Friedrich FPHSR36A3B User Manual

87 PB
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
21 67400588 4113865 ‑ panel FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
22 67400589 1964953 ‑ Motor bracket FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
23 67400590 1964954 ‑ motor cover FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
24 67400591 1964950 ‑ center staff FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
25 67400592 1964956 ‑ motor cover FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
26 67400174 1260259 ‑ Step motor FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
27 67400550 1964955 ‑ Motor bracket FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
28 67400595 1467336 ‑ Step motor FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
29 67400596 1964945 ‑ ornamental part FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
30 67400485 1964949 ‑ bafe FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 2
31 67400598 1964939 ‑ axes FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 2
32 67400599 1964940 ‑ wiring distribution
cover assy
FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
33 67400600 1964938 ‑ decorative panel FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
34 67400487 1978713 ‑ Water pipe parts FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
35 67400602 1964936 ‑ Motor hoop FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 2
36 67400326 2006737 ‑ AC motor FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
37 67400603 1964934 ‑ motor guard FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
38 67400604 1961612 ‑ electric box cover FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
39 67400489 1961613 ‑ button FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
40 67400490 1988669 ‑ Power Switch FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
41 67400559 1988777 ‑ Jiggle switch FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
42 67400786 1959674 ‑ electric box FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
43 67400609 1961611 ‑ electric box FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
44 67400313 2009266 ‑ 9K Indoor Main
Control Board Component
FPHSW09A1A, FPHSW09A1B 1
44 67400317 2010485 ‑ 12K Indoor Main
Control Board Component
FPHSW12A1A, FPHSW12A1B 1
45 67400166 1852126 ‑ Wire terminal board FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
46 67400611 1959675 ‑ guard cover FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
47 67400612 2010238 ‑ guard cover FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
48 67400161 4084109 ‑ Remote Controller FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
49 67400494 1831400 ‑ Temperature sensor FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
50 67400495 1965628 ‑ Temperature sensor FPHSW09A1A, FPHSW09A1B, FPHSW12A1A, FPHSW12A1B 1
‑51 67401169 WIFI module FPHSW09A1B, FPHSW12A1B 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
PARTS CATALOG
115V Indoor Unit 9-12K
FIgure 901

Friedrich FPHSR36A3B Specifications

General

Brand	Friedrich
Model	FPHSR36A3B
Category	Air Conditioner
Language	English
