PARTS CATALOG

230V Indoor Unit High Seer 9K

Figure 903

ITEM PART

NUMBER

PART DESCRIPTION USED ON MODEL QTY

22 67400589 1964953 ‑ Motor bracket FRHSW09A3A, FRHSW09A3B 1

23 67400590 1964954 ‑ motor cover FRHSW09A3A, FRHSW09A3B 1

24 67400591 1964950 ‑ center staff FRHSW09A3A, FRHSW09A3B 1

25 67400592 1964956 ‑ motor cover FRHSW09A3A, FRHSW09A3B 1

26 67400174 1260259 ‑ Step motor FRHSW09A3A, FRHSW09A3B 1

27 67400550 1964955 ‑ Motor bracket FRHSW09A3A, FRHSW09A3B 1

28 67400595 1467336 ‑ Step motor FRHSW09A3A, FRHSW09A3B 1

29 67400596 1964945 ‑ ornamental part FRHSW09A3A, FRHSW09A3B 1

30 67400485 1964949 ‑ bafe FRHSW09A3A, FRHSW09A3B 1

31 67400598 1964939 ‑ axes FRHSW09A3A, FRHSW09A3B 1

32 67400599 1964940 ‑ wiring distribution cover assy FRHSW09A3A, FRHSW09A3B 1

33 67400600 1964938 ‑ decorative panel FRHSW09A3A, FRHSW09A3B 1

34 67400487 1978713 ‑ Water pipe parts FRHSW09A3A, FRHSW09A3B 1

35 67400602 1964936 ‑ Motor hoop FRHSW09A3A, FRHSW09A3B 1

36 67400331 1838324 ‑ DC motor FRHSW09A3A, FRHSW09A3B 1

37 67400603 1964934 ‑ motor guard FRHSW09A3A, FRHSW09A3B 1

38 67400604 1961612 ‑ electric box cover FRHSW09A3A, FRHSW09A3B 1

39 67400489 1961613 ‑ button FRHSW09A3A, FRHSW09A3B 1

40 67400490 1988669 ‑ Power Switch FRHSW09A3A, FRHSW09A3B 1

41 67400559 1988777 ‑ Jiggle switch FRHSW09A3A, FRHSW09A3B 1

42 67400786 1959674 ‑ electric box FRHSW09A3A, FRHSW09A3B 1

43 67400609 1961611 ‑ electric box FRHSW09A3A, FRHSW09A3B 1

44 67401203 2083288 ‑ Indoor Main Control Board Component FRHSW09A3A, FRHSW09A3B 1

45 67400166 1852126 ‑ Wire terminal board FRHSW09A3A, FRHSW09A3B 1

46 67400611 1959675 ‑ guard cover FRHSW09A3A, FRHSW09A3B 1

47 67400612 2010238 ‑ guard cover FRHSW09A3A, FRHSW09A3B 1

48 67400161 4084109 ‑ Remote Controller FRHSW09A3A, FRHSW09A3B 1

49 67400494 1831400 ‑ Coil pipe Temperature Sensor FRHSW09A3A, FRHSW09A3B 1

50 67400495 1965628 ‑ Ambient Temperature Sensor FRHSW09A3A, FRHSW09A3B 1

‑51 67401169 WIFI module FRHSW09A3B 1

‑ITEMS ARE NON‑ ILLUSTRATED
