Friedrich FPHSR36A3B User Manual

93 PB
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
13 67400474 1961606 ‑ ornamental part FRHSW12A3A, FRHSW12A3B 1
14 67400476 2015970 ‑ Vertical Level Vane FRHSW12A3A, FRHSW12A3B 1
15 67400591 1964950 ‑ center staff FRHSW12A3A, FRHSW12A3B 2
16 67401212 2015958 ‑ center staff FRHSW12A3A, FRHSW12A3B 1
17 67401213 2015959 ‑ center staff FRHSW12A3A, FRHSW12A3B 2
18 67401214 1961598 ‑ level vane FRHSW12A3A, FRHSW12A3B 2
19 67400238 1541386 ‑ Filter net FRHSW12A3A, FRHSW12A3B 2
20 67401193 1898705 ‑ Display Component FRHSW12A3A, FRHSW12A3B 1
21 67401215 4113866 ‑ panel FRHSW12A3A, FRHSW12A3B
22 67400547 1961607 ‑ Motor bracket FRHSW12A3A, FRHSW12A3B 1
23 67400548 1961610 ‑ motor cover FRHSW12A3A, FRHSW12A3B 1
24 67401216 2015960 ‑ center staff FRHSW12A3A, FRHSW12A3B 2
25 67400592 1964956 ‑ motor cover FRHSW12A3A, FRHSW12A3B 1
26 67400174 1260259 ‑ Step motor FRHSW12A3A, FRHSW12A3B 1
27 67400550 1964955 ‑ Motor bracket FRHSW12A3A, FRHSW12A3B 1
28 67400222 1819726 ‑ Step motor FRHSW12A3A, FRHSW12A3B 1
29 67400475 1961608 ‑ ornamental part FRHSW12A3A, FRHSW12A3B 1
30 67400485 1964949 ‑ bafe FRHSW12A3A, FRHSW12A3B 1
31 67400598 1964939 ‑ axes FRHSW12A3A, FRHSW12A3B 1
32 67401194 1961602 ‑ wiring distribution cover assy FRHSW12A3A, FRHSW12A3B 1
33 67401217 1961601 ‑ decorative panel FRHSW12A3A, FRHSW12A3B 1
34 67400487 1978713 ‑ Water pipe parts FRHSW12A3A, FRHSW12A3B 1
35 67400602 1964936 ‑ Motor hoop FRHSW12A3A, FRHSW12A3B 1
36 67400219 1561454 ‑ DC motor FRHSW12A3A, FRHSW12A3B 1
37 67401218 1964339 ‑ motor guard FRHSW12A3A, FRHSW12A3B 1
38 67400604 1961612 ‑ electric box cover FRHSW12A3A, FRHSW12A3B 1
39 67400489 1961613 ‑ button FRHSW12A3A, FRHSW12A3B 1
40 67400490 1988669 ‑ Power Switch FRHSW12A3A, FRHSW12A3B 1
41 67400559 1988777 ‑ Jiggle switch FRHSW12A3A, FRHSW12A3B 1
42 67400786 1959674 ‑ electric box FRHSW12A3A, FRHSW12A3B 1
43 67400609 1961611 ‑ electric box FRHSW12A3A, FRHSW12A3B 1
44 67401219 2087176 ‑ Indoor Main Control Board Component FRHSW12A3A, FRHSW12A3B 1
45 67400166 1852126 ‑ Wire terminal board FRHSW12A3A, FRHSW12A3B 1
46 67400611 1959675 ‑ guard cover FRHSW12A3A, FRHSW12A3B 1
47 67400612 2010238 ‑ guard cover FRHSW12A3A, FRHSW12A3B 1
48 67400161 4084109 ‑ Remote Controller FRHSW12A3A, FRHSW12A3B 1
49 67400494 1831400 ‑ Temperature sensor FRHSW12A3A, FRHSW12A3B 1
50 67400495 1965628 ‑ Temperature sensor FRHSW12A3A, FRHSW12A3B 1
‑51 67401169 WIFI module FRHSW12A3B 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
PARTS CATALOG
230V Indoor Unit High Seer12K
FIgure 904
