97 PB
PARTS CATALOG
230V Indoor Unit 24K
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
19 #N/A
20 67400479 1961594 ‑ Wire Louver FPHFW24A3A, FPHFW24A3B 1
21 67400480 1541387 ‑ Filters FPHFW24A3A, FPHFW24A3B 1
22 67400236 1824935 ‑ Display Kit FPHFW24A3A, FPHFW24A3B 1
23 67400482 4117900 ‑ panel FPHFW24A3A, FPHFW24A3B 1
24 67400547 1961607 ‑ Motor bracket FPHFW24A3A, FPHFW24A3B 1
25 67400548 1961610 ‑ Main Front Panel FPHFW24A3A, FPHFW24A3B 1
28 67400174 1260259 ‑ Stepper Motor FPHFW24A3A, FPHFW24A3B 1
29 67400550 1964955 ‑ Stepper Motor Bracket FPHFW24A3A, FPHFW24A3B 1
30 67400222 1819726 ‑ Lower Stepper Motor
with Wire
FPHFW24A3A, FPHFW24A3B 1
31 67400485 1964949 ‑ Louver Pins FPHFW24A3A, FPHFW24A3B 1
32 67400598 1964939 ‑ Frame Pins FPHFW24A3A, FPHFW24A3B 1
33 #N/A
34 67400487 1978713 ‑ Drain Pipe FPHFW24A3A, FPHFW24A3B 1
35 #N/A
36 67400488 1561456 ‑ Blower Motor FPHFW24A3A, FPHFW24A3B 1
39 67400489 1961613 ‑ Panel Switch FPHFW24A3A, FPHFW24A3B 1
40 67400490 1988669 ‑ Front Switch FPHFW24A3A, FPHFW24A3B 1
41 67400559 1988777 ‑ Board Switch FPHFW24A3A, FPHFW24A3B 1
42 #N/A
43 #N/A
44 67400560 2019039 ‑ Indoor Main Control
Board
FPHFW24A3A, FPHFW24A3B 1
45 #N/A
46 67400166 1852126 ‑ Terminal Block FPHFW24A3A, FPHFW24A3B 2
47 #N/A
48 #N/A
49 #N/A
50 67400494 1831400 ‑ Upper Thermistor FPHFW24A3A, FPHFW24A3B 2
51 67400495 1965628 ‑ Lower Thermistor FPHFW24A3A, FPHFW24A3B 1
52 67400161 4084109 ‑ Remote Control FPHFW24A3A, FPHFW24A3B 1
‑53 67401169 WIFI module FPHFW24A3B 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED LEAD TIME
Figure 906
