Remote Control -RefertoFigure340Aduringoperationdescription.
Getting Started -Installtwo(2)AAAbatteriesinthebatterycompartmentlocatedonthebackoftheunit.
Operation -Theremotecontrolshouldbewithin25feetoftheairconditionerforoperation(refertoFigure340Bforeffectiveness).
Pressthepowerbuttontoturntheremoteon.Theremotewillautomaticallypoweroffafter15secondsifthebuttonsarenot
beingpressed.Theremotemustbeontocontroltheunit.
POWER Button -Turnsremoteandunitonandoff.
MODE Button - Allows the user to sequentially select the following: AUTO,
COOL,HEAT,andFANONLYoperations.Whenthebuttonispressed,thedisplay
indicateswhichmodehasbeenselectedviaadisplaymessage.Notethatwhen
theheatingfunctionisnotavailable,thesystemwillautomaticallyskiptheHEAT
mode.
FAN Button - Selectsbetweenautomatic(AUTOFAN)orCONTINUOUSoperation.
In the AUTO FAN mode, the fan only turns on and off when the compressor
operatesortheheatfunctionisenabled.
NOTE: AUTOFANisnotavailableintheFANONLYMode,thedisplayindicates
CONTINUOUS. In the CONTINUOUS mode, fan speed is determined by your
selectionontheFANSPEEDbutton.
SPEED Button - Used to sequentially select new fan speed, plus AUTO
operation. When the FAN SPEED button is pressed, the fan speed icon
(triangle) changes to indicate the new speed level. Fan speed automatically
variesdependingonthesettemperatureonthecontrolpanelandtheactual
room temperature. For example, if there is a big difference between your
set temperature and the actual room temperature, the system fan speed
increasestoHIGH.Itremainsatthisspeeduntiltheroomtemperature
matchesthesettemperature.
UP and DOWN Arrows - Pressingeither theUPor DOWNbuttonchanges
the desiredroom temperature.The factorypreset lowerand upper limits
are60°F(16°C)and99°F(37°C).Thesebuttonsarealsousedtonavigate
betweenfunctionoptionswhenusingtheUserMenuorMaintenanceMode.
Remote Effectiveness
Handheld Remote - Has an operating range
ofupto25ft.Theinfraredremotecontrol
signalmust haveaclearpathto transmit
thecommand to theair conditioningunit.
The remote signal has some ability to
“bounce” off of walls and furniture similar
toa televisionremotecontrol.Thediagram
belowshowsthetypicaloperating rangeof
thecontrolinastandardroomwith8fthigh
ceilings.
30°
45°
60°
30°
45°
60°
25ft
25ft
8ft
4ft
25ft
16ft
6ft
30°
30°
45°
60°
45°
60°
25ft
25ft
25ft
8ft
25ft
25ft
7.5ft
TOP VIEW
OPERATION
Remote Control
FIGURE 340B (REMOTE CONTROL)
POWER
MODE
UP and
DOWN
ARROWS
FAN
SPEED
SIDE VIEW
FIgure 340A (Remote Control)
