ROOM AIR CONDITIONER UNIT PERFORMANCE TEST DATA SHEET
JOBNAME______________________TECH’SNAME_________________________
DATE___________ MODEL#_______________ SERIAL #______________________
CHECK THE INSTALLATION ACCEPTABLE NOT ACCEPTABLE
YES NO
ISACHASISGASKETINSTALLED?   _____  ____
ISTHEFRESH/EXHAUSTAIRVENTOPEN?  _____  ____
ISAFRIEDRICHSLEEVEINSTALLED?  _____  ____
ISAFRIEDRICHOUTDOORGRILLEINSTALLED? _____  ____
ISMAINTENANCEBEINGPERFORMED?  _____  ____
ELECTRICAL
 LINEVOLTAGE(STATIC)    _____VOLTS
 STARTUPVOLTAGE     _____VOLTS
 AMPERAGEDRAW(COOL)    _____AMPS
 AMPERAGEDRAW(HEAT)    _____AMPS
COMPRESSOR
LOCKED ROTOR AMPS _____ AMPS
 RUNNINGAMPERAGEDRAW    _____AMPS
INDOOR CONDITIONS
INDOOR AMBIENT TEMPERATURE _____ F
RELATIVE HUMIDITY (RH) INDOOR _____%
 DISCHARGEAIRTEMPERATURE(INDOOR)(COOL)  _____F
 DISCHARGEAIRTEMPERATURE(INDOOR)(HEAT)  _____F
RETURN AIR TEMPERATURE (INDOOR)(COOL) _____F
RETURN AIR TEMPERATURE (INDOOR) (HEAT) _____F
OUTDOOR TEMPERATURE
OUTDOOR AMBIENT TEMPERATURE _____F
RH OUTDOOR RELATIVE HUMIDITY _____%
 DISCHARGEAIRTEMPERATURE(OUTDOOR)(COOL) _____F
 DISCHARGEAIRTEMPERATURE(OUTDOOR)(HEAT) _____F
INTAKE AIR TEMPERATURE (OUTDOOR)(COOL) _____F
INTAKE AIR TEMPERATURE (OUTDOOR)(HEAT) _____F
COOLING OR HEATING AREA
 AREAW______*L_______=FEETSQUARED
FORAGENERALGUIDEREFERTOSIZINGGUIDETOTHERIGHT
FOREXACTLOADCALCULATIONSCONSULTMANUALJORM.
COOLING SIZING GUIDE
AREA TO BE
CONDITIONED
IN SQ. FT.
APPROXIMATE
COOLING BTU
REQUIRED
100-150 5000
150-250 6000
250-300 7000
300-350 8000
350-400 9000
400-450 10000
450-550 12000
550-700 14000
700-1000 18000
1000 - 1200 21000
1200 - 1400 23000
1400-1500 24000
1500-2000 30000
2000-2500 34000
Guide based on normal room
insulation, average number of
sun exposed windows and two
person occupancy.
1. If heavily shaded, reduce
cooling Btus required by 10%
2. If very sunny, increase cool-
ing Btus required by 10%
3. Add 500 Btus per person
over 2 people
4. Add 4,000 Btus if the area is
a kitchen
TROUBLESHOOTING
Figure 708 (Test Data Sheet)
Figure 709 (Cooling Sizing Guide)
