COMPONENTS TESTING
Heating Element
WARNING
ELECTRIC SHOCK HAZARD
Turn off electric power before service or
installation. Extreme care must be used, if it
becomes necessary to work on equipment with
power applied.
Failure to do so could result in serious injury or
death.
Heating Element
Example
Electricheatmodelsareequippedwithaheatingelement
TheKEQ08A11AModelisequippedwitha1.15kw(@115Volts)HeatingElement.
Theheatingelementcontainsafuselinkandaheaterlimitswitch.Thefuselinkisinserieswiththepowersupplyandwill
openandinterruptthepowerwhenthetemperaturereaches199°Forashortcircuitoccursintheheatingelement.Oncethe
fuselinkseparates,anewheaterelementmustbeinstalled.
NOTE:Alwaysreplaceheatingelementwiththeexactreplacement.
Theheaterelementhasahighlimitcontrol.Thiscontrolisabimetalthermostatmountedinthetopoftheheatingelement.
Shouldthefanmotorfailorlterbecomeclogged,thehighlimitcontrolwillopenandinterruptpowertotheheaterbefore
reachinganunsafetemperaturecondition.
Thecontrolisdesignedtoopenat110°F±6°F.Testcontinuitybelow110°Forwhenitiscooledoff.
TESTING THE HEATING ELEMENT
Testingoftheelementscanbemadewithanohmmeteracrosstheterminalsaftertheconnectingwireshavebeenremoved.
Acoldresistancereadingofapproximately10.11ohmsforthe1.15KWheatershouldberegistered.
DRAIN PAN VALVE
Duringthecoolingmodeofoperation,condensatewhichcollectsinthedrainpanispickedupbythecon-denserfanbladeand
sprayedontothecondensercoil.Thisassistsincoolingtherefrigerantplusevaporatingthewater.
Duringtheheatingmodeofoperation,itisnecessarythatwaterberemovedtopreventitfromfreezingduringcoldoutside
temperatures.Thiscouldcausethecon-denserfanbladetofreezeintheaccumulatedwaterandpreventitfromturning.
Toprovideameansofdrainingthiswater,abellowstypedrainvalveisinstalledoveradrainopeninginthebasepan.
Thisvalveistemperaturesensitiveandwillopenwhentheoutsidetemperaturereaches40°F.Thevalvewillclosegraduallyas
thetemperaturerisesabove40°Ftofullycloseat60°F.
DRAIN PAN VALVE
Duringthecoolingmodeofoperation,condensatewhichcollectsinthedrainpanispickedupbythecon-denserfanbladeand
sprayedontothecondensercoil.Thisassistsincoolingtherefrigerantplusevaporatingthewater.
Duringtheheatingmodeofoperation,itisnecessarythat
waterberemovedtopreventitfromfreezingduringcold
outsidetemperatures.Thiscouldcausethecon-denserfan
bladetofreezeintheaccumulatedwaterandpreventitfrom
turning.
To provide a means of draining this water, a bellows type
drainvalveisinstalledoveradrainopeninginthebasepan.
This valve is temperature sensitive and will open when the
outsidetemperaturereaches40°F.Thevalvewillclose
graduallyasthetemperaturerisesabove40°Ftofullyclose
at60°F.
Bellows Assembly
Drain Pan Valve
Figure 704 (Heating Element)
Figure 705 Drain Pan Valve
