Friedrich Kuhl+ KEQ08A11A User Manual

71 PB
FIGURE 902
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
5 61850204 CONDENSOR COIL
QCS5MMX4X16RC9X39A15H2
KCQ06A10A, KCQ08A10A, KEQ08A11A 1
5 61850206 CONDENSOR COIL
QCS5MMX4X16RC9X39A15H2
KCQ10A10A 1
10 61600275 EVAPORATOR COIL
QES.312X3X18RC2E45A15X09H6
KCQ08A10A, KCQ10A10A, KEQ08A11A 1
10 61600274 EVAPORATOR COIL
QES.312X3X18RC2E45A15X09H6
KCQ06A10A 1
15 61627601 SHROUD 'Q' ALL 1
20 61718126 KITCOMPRRPLMNT62200315 KCQ08A10A, KEQ08A11A 1
20 61717183 KIT COMPR RPLMNT 62200141 KCQ06A10A 1
20 61718135 KIT COMPR RPLMNT 62200142 KCQ10A10A 1
25 91400402 STUDCOMPMTG ALL 3
30 61028904 GROMMETCOMPLOWDENSITY ALL 3
35 61883101 PAD ISOLATION 2X4 ALL 1
45 67000205 CAP TUBE ASSY KIT
(INCLUDES CAP TUBE ASSY
(PN 61920268), STRAINER, AND
STRAINER HOLDER
KCQ08A10A , KEQ08A11A 1
45 67000206 CAP TUBE ASSY KIT
(INCLUDES CAP TUBE ASSY
(PN61920276),STRAINER,AND
STRAINER HOLDER
KCQ06A10A 1
45 67000207 CAP TUBE ASSY KIT
(INCLUDES CAP TUBE ASSY
(PN61920276),STRAINER,AND
STRAINER HOLDER
KCQ10A10A 1
40 61626312 BASEPANQCHASSISRG/QA KCQ06A10A, KCQ08A10A, KCQ10A10A 1
40 61626314 BASEPANQCHASSISRG/QA KEQ08A11A 1
50 61834800 STRAINER.312COIL ALL 1
55 61835001 STRAINER HOLDER ALL 1
60 61638400 DRAIN PAN ALL 1
65 60179904 CONDENSATE DRAIN VALVE KEQ08A11A 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED
PARTS CATALOG
