134 PB
ITEM op-nd PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
80 060010 80083814 CONTROL BOX ALL 1
81 060171 80080227 HEATER BOARD STAND OFF ALL 4
82 060070 63900141 PCBA, FRIEDRICH HEATER
CONTROLLER (FHC)
ALL 1
83 060120 80083723 BLOCK TERM 3 POLES X 6QC TAB#2‑
14
ALL 6
84 010279 80083438 FUSE HOLDER BASEPAN HEAT 1
85 010281 80060030 FUSE 3AB 1.0A, 400VDC, TIME DELAY BASEPAN HEAT 1
86 060040 62623408 DRIVER BOARD ALL 1
87 060101 62623401 SUPPLY, DC POWER 12V, 2A, 85‑
265VAC
ALL 1
88 060102 61600532 STAND OFF ‑ PCB DIA .125 ALL 4
89 060081 80080227 FMC BOARD STAND OFF ALL 4
90 060090 80083543 SD CARD ASSEMBLY FOR THE MAIN
BOARD (FMC)
ALL 1
91 060080 62622001 FMC BOARD ALL 1
92 060170 80083432 RELAY, 12VDC COIL X 30A REHEAT 1
93 050232 80083432 RELAY, 12VDC COIL X 30A FRESH AIR 1
94 100131 80083202 5 PIN WALL CONTROLLER PLUG ALL 1
95 060104 80080227 STAND OFF ‑ PCB DIA.156 X .5 H ALL 4
96 060103 62623403 PCBA, RS‑485 CONVERTER ALL 1
97 060041 62623409 INDUCTOR‑REACTOR, DC INVERTER
1 TON"
ALL 1
111 040014 80083702 SENSOR RETURN AIR TEMP WHT ALL 1
112 040015 80083703 SENSOR EVAP COIL IN GRN ALL 1
113 040016 80083704 SENSOR DISCHARGE AIR YEL ALL 1
114 040017 80083705 SENSOR COMPRESSOR DISCHARGE
BLK
ALL 1
115 040018 80083706 SENSOR COMPRESSOR SUCTION BLU ALL 1
116 040019 80083707 SENSOR HEATING LIQUID BRW ALL 1
117 040020 80083708 SENSOR COOLING LIQUID ORG ALL 1
118 040021 80083709 SENSOR CONDENSER OUT PNK ALL 1
119 040022 80083710 SENSOR AMBIENT RED ALL 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE EXTENDED DAYS LEAD TIME
PARTS CATALOG
12K E Models (230v Electrical Controls)
