Friedrich VRP Series Service & Parts Manual

22 PB
SPECIFICATIONS
12k and 24k Accessories Dimensional Data - Wall Plenums
Accessory Description Outer Dimensions
VRPXWPA-8 Compact Wall Plenum for 4" to 8" thick wall
VRPXWPB-8 Standard Wall Plenum for 4" to 8" thick wall
28
7
/8" (W) x 33
3
/8" (H)
VRPXWPA-14 Compact Wall Plenum for 8" to 14" thick wall
28
7
/8" (W) x 43
3
/8" (H)
VRPXWPB-14 Standard Wall Plenum for 8" to 14" thick wall
28
7
/8" (W) x 33
3
/8" (H)
28
7
/8" (W) x 43
3
/8" (H)
PAR T B
INSIDE PLE NU M
PAR T A
OUTSIDE PLENUM
45°
DR IP LEDGE
PART A
OUTSIDE PLE NUM
PART B
29 1/8 in.
27 5/8 in.
32 in.
1 1/2 in.
7 1/2 in.
6 3/4 in.
TYP
INSIDE PLENUM
19 in.
TYP
7 1/2 in.
45
○
28 3/4 in.
33 3/8 in.
45°
DRIP LEDGE
PART A
OUTSIDE PLE NU M
PAR T B
INSIDE PLENUM
PAR T A
OUTSIDE PLENUM
PAR T B
INSIDE PLENUM
7 1/2 in
28 3/4 in
27 3/8 in
41 7/8 in
43 3/8 in
45°
7 1/2 in
2 in
TYP.
10 1/2 in
TYP.
10 3/8 in
TYP.
1 1/2 in
TYP.
29 in
6 3/4 in
TYP.
TYP.
42 in
27 3/4 in
29 1/8 in
43 3/8 in
Installation Guidelines
Wall Plenum for VRP12 with VRPXWPA-8/14 "
Wall Plenum for VRP24 with VRPXWPB-8/14 "
• Chassis is to be installed
against an exterior wall.
Refer to page 11 for wall cut
out dimensions
• 32" x 32" recommended
minimum closet dimensions
for return air, drain
connections and change outs
• Minimum recommended
access door rough-in
measurements: 30" wide by
69
3
/4" high
• The use of a Friedrich wall
plenum is required for
installation. Refer to this
page for different sizes and
selection guide
• Plenum opening minimum
edge of outside wall cut out
should be 3"
• Wall plenum allows chassis to
be inserted 2
3
/8" into plenum
• Return air is accommodated
to the unit or through the use
(VRPXAP1).
• Exterior louvers are available
in anodized aluminum or in
custom painted colors and two
different sizes: One for only
12K Btu units and the other
that can be used with either
12K or 24K units. Refer to
page 12 for details
• Unit is controlled by a remote
wall-mounted ‘Controller’
Figure 209(12k and 24k Accessories Dimensional Data - Wall Plenums)
