Friedrich VRP Series Service & Parts Manual

14 PB
SPECIFICATIONS
Cooling Performance
Figure 201 (Cooling Performance)
Model VRP12K / VRP12R
Cooling Performance Data (Cooling Standards: 95°F
DB/75°F WB outdoor, 80°F DB/67°F WB indoor)
Voltage 230/208 265
Cooling Btu (Rated) 11,500
Cooling Btu (Min. – Max) 5,400– 16,000
Outdoor Operating
Range (°F)
55 – 115
Power (W) 927
SEER 17.4
EER 12.4
Sensible Heat Ratio 0.71
Cooling Amps 5.3 4.6
Heat Pump Performance Data
Heating Btu (Rated @ 47° F) 11,200
Heating Btu (@ 17° F) 7,700
Heating Btu (Min. – Max.) 4,000 – 14,000
Heat Pump Outdoor
Operating Range (°F)*
0 – 70
COP (Rated @ 47° F) 3.4
COP (@ 17° F) 2.2
HSPF 10.0
Heating Power (W) 1058
Heating Amps 5.3 4.7
