39 PB
OPERATION
Component Identication
Reheat Control
• The VRP models, when equipped with
the reheat option, increase room
dehumidification capability.
• The reheat option has a coil installed
downstream of the main indoor
evaporator coil.
• When activated, a portion of the
compressor discharge gas is routed
through the reheat coil.
• This coil “reheats” the air leaving the
evaporator and allows longer run times
for additional dehumidification without
over-cooling the room.
Evaporator Coil
Reheat Coil
FIGURE 314 (COMPONENT IDENTIFICATION-REHEAT CONTROL)
