Friedrich VRP Series Service & Parts Manual

15 PB
SPECIFICATIONS
12k/24k Extended Cooling Performance Data
Figure 202 (12k/ 24k Extended Cooling Performance Data)
11
VRP Extended Cooling Performance Data
Model:
VRP12
Indoor Temperature
70˚ FDB 75˚ FDB 80˚ FDB 85˚ FDB 90˚ FDB
60˚ F WB 63˚ F WB 67˚ F WB 71˚ F WB 73˚ F WB
Outdoor Temperature Dry (°F)
(˚F)
DB
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
65˚
11680 615 2.8 12755 615 2.8 13825 615 2.8 14900 615 2.8 15975 620 2.8
70˚
11460 665 3.0 12510 665 3.0 13555 675 3.0 14600 675 3.0 15650 675 3.0
75˚
11240 720 3.2 12260 720 3.2 13280 725 3.2 14300 725 3.2 15320 725 3.2
80˚
10990 765 3.4 11980 775 3.5 12970 775 3.5 13965 775 3.5 14955 780 3.5
85˚
10735 815 3.6 11700 820 3.7 12660 825 3.7 13625 825 3.7 14585 830 3.7
90˚
10460 860 3.9 11400 870 3.9 12330 875 3.9 13270 880 3.9 14200 880 3.9
95˚
10185 910 4.1 11090 920 4.1 12000 925 4.1 12910 930 4.2 13815 935 4.2
100˚
9875 960 4.3 10760 970 4.3 11645 975 4.4 12530 985 4.4 13415 990 4.4
105˚
9565 1010 4.5 10425 1020 4.6 11285 1030 4.6 12145 1040 4.7 13005 1045 4.7
110˚
9265 1060 4.7 10100 1075 4.8 10940 1085 4.9 11775 1100 4.9 12610 1110 5.0
115˚
8965 1120 5.0 9775 1130 5.1 10590 1145 5.1 11400 1155 5.2 12215 1170 5.2
Cooling Standards: 95°F DB/75°F WB outdoor, 80°F DB/67°F WB indoor. Values reect performance at A2 rated compressor frequency.
Model:
VRP07
Indoor Temperature
70˚ FDB 75˚ FDB 80˚ FDB 85˚ FDB 90˚ FDB
60˚ F WB 63˚ F WB 67˚ F WB 71˚ F WB 73˚ F WB
Outdoor Temperature Dry (°F)
(˚F)
DB
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
65˚
7790 450 2.3 8505 450 2.3 9220 450 2.3 9935 450 2.3 10655 455 2.3
70˚
7480 475 2.4 8170 475 2.4 8850 480 2.4 9530 480 2.4 10220 480 2.4
75˚
7175 505 2.6 7830 505 2.6 8480 510 2.6 9130 510 2.6 9785 510 2.6
80˚
6870 540 2.6 7490 545 2.7 8110 545 2.7 8730 545 2.7 9350 550 2.7
85˚
6565 570 2.8 7155 570 2.9 7740 575 2.9 8330 575 2.9 8915 580 2.9
90˚
6250 595 3 6815 600 3 7370 605 3 7930 610 3 8490 610 3
95˚
5940 625 3.2 6470 630 3.2 7000 635 3.2 7530 640 3.3 8060 640 3.3
100˚
5620 655 3.3 6125 660 3.3 6630 665 3.4 7135 670 3.4 7640 675 3.4
105˚
5305 685 3.4 5785 695 3.5 6260 700 3.5 6735 705 3.6 7215 710 3.6
110˚
4990 715 3.5 5440 725 3.6 5890 730 3.7 6340 740 3.7 6790 745 3.8
115˚
4675 745 3.7 5095 750 3.8 5520 760 3.8 5940 765 3.9 6365 775 3.9
12
VRP Extended Cooling Performance Data
Model:
VRP24
Indoor Temperature
70˚ FDB 75˚ FDB 80˚ FDB 85˚ FDB 90˚ FDB
60˚ F WB 63˚ F WB 67˚ F WB 71˚ F WB 73˚ F WB
Outdoor Temperature Dry (°F)
(˚F)
DB
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
65˚
22875 1420 6.4 24980 1420 6.4 27075 1420 6.4 29180 1420 6.4 31285 1430 6.4
70˚
22440 1535 6.8 24500 1535 6.8 26545 1560 6.8 28590 1560 6.8 30650 1560 6.8
75˚
22010 1665 7.3 24010 1665 7.3 26005 1675 7.3 28005 1675 7.3 30000 1675 7.3
80˚
21520 1765 7.7 23460 1790 7.9 25400 1790 7.9 27350 1790 7.9 29285 1800 7.9
85˚
21025 1880 8.2 22910 1895 8.4 24795 1905 8.4 26680 1905 8.4 28560 1915 8.4
90˚
20485 1985 8.8 22325 2010 8.8 24145 2020 8.8 25985 2030 8.8 27810 2030 8.8
95˚
19945 2100 9.3 21720 2125 9.3 23500 2135 9.3 25280 2150 9.5 27055 2160 9.5
100˚
19340 2215 9.8 21070 2240 9.8 22805 2250 10 24540 2275 10 26270 2285 10
105˚
18730 2330 10.2 20415 2355 10.4 22100 2380 10.4 23785 2400 10.7 25470 2415 10.7
110˚
18145 2450 10.7 19780 2480 10.9 21425 2505 11.1 23060 2540 11.1 24695 2565 11.3
115˚
17555 2585 11.3 19145 2610 11.6 20740 2645 11.6 22325 2665 11.8 23920 2700 11.8
Model:
VRP36
Indoor Temperature
70˚ FDB 75˚ FDB 80˚ FDB 85˚ FDB 90˚ FDB
60˚ F WB 63˚ F WB 67˚ F WB
71 F WB
73˚ F WB
Outdoor Temperature Dry (°F)
(˚F)
DB
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
Capacity
(Btu/h)
Input
(W)
Amps
(A)
65˚
31425 2265 2.3 34315 2265 9.8 37195 2265 2.3 40090 2265 2.3 42980 2285 2.3
70˚
30910 2365 2.4 33745 2365 10.5 36565 2400 2.4 39380 2400 2.4 42215 2400 2.4
75˚
30410 2515 2.6 33170 2515 11.2 35930 2530 2.6 38690 2530 2.6 41450 2530 2.6
80˚
29910 2630 2.6 32605 2665 11.9 35300 2665 2.7 38005 2665 2.7 40700 2680 2.7
85˚
29395 2760 2.8 32035 2780 12.6 34665 2795 2.9 37310 2795 2.9 39935 2810 2.9
90˚
28870 2880 3 31465 2910 13.3 34035 2930 3 36625 2945 3 39195 2945 3
95˚
28350 3010 3.2 30865 3045 14 33400 3060 3.2 35935 3075 3.3 38450 3095 3.3
100˚
27785 3145 3.3 30275 3175 14.7 32765 3190 3.4 35260 3225 3.4 37750 3240 3.4
105˚
27235 3260 3.4 29685 3290 15.4 32135 3325 3.5 34585 3355 3.6 37030 3375 3.6
110˚
26680 3375 3.5 29085 3425 16.1 31500 3455 3.7 33905 3505 3.7 36310 3535 3.8
115˚
26130 3510 3.7 28495 3540 16.8 30870 3590 3.8 33230 3620 3.9 35605 3670 3.9
Cooling Standards: 95°F DB/75°F WB outdoor, 80°F DB/67°F WB indoor. Values reect performance at A2 rated compressor frequency.
