17 PB
SPECIFICATIONS
Air Flow Data -12k and 24k
Figure 204 (12K and 24K Air Flow Data)
9
Air Flow Data
Model VRP12K / R VRP24K / R
Air Flow Data
Indoor CFM Low High Low High
.10” ESP * 488 559 472 850
.20” ESP 393 466 432 778
.30” ESP 292 383 391 703
.40” ESP 200 304 348 626
.50” ESP 104 234 308 555
* Rated at 0.10" ESP, High and includes 0.08 ESP for factory installed 1" lter
Condenser CFM & External Static Pressure
VRP
®
is designed to mount through an exterior wall through a Friedrich wall plenum with an external louver.
Building design and applications may require different congurations of this external connection for aesthetic/architectural reasons.
These different congurations may include custom louvers, plenums or special ducted returns.
The following are guidelines for the design of these custom external congurations.
Condenser External Static Pressure
VRP Model
Design Maximum
CFM
ESP ("WC) ESP ("WC)
VRP 12000 Btu 700 0.03 0.1
VRP 24000 Btu 1150 0.017 0.11
Indoor CFM & External Static Pressure
CAUTION: If the Friedrich designed plenum and louver combinations are not used, the louver/duct design must be evaluated to
insure the total pressure drop does not exceed the maximum allowable limits.
