Friedrich VRP Series Service & Parts Manual

21 PB
SPECIFICATIONS
12k and 24k Accessories Dimensional Data-Louvers & Return Access Door
18
Return Air Access Panel VRPXAP1 32" x 72"
12K LOUVERED GRILLE
20 in.
1 1/8 in
2 3/4 in
2 3/8 in
29 1/8 in
33 3/8 in
30
○
4 in.
4 in.
24K LOUVERED GRI LLE
4 in.
2 1/2 in
4 in.
29 1/8 in
43 3/8 in
2 3/4 in
1 1/8 in
30
○
Accessory Description Outer Dimensions
VRPXALA
Architectural louver (VRP12 only) (30 ˚ Blade angle)
VRPXALB
29
1
/8" W x 33
3
/8" H
Architectural louver (VRP24) (30 ˚ Blade angle) (Can also be used for VRP12)
VRPXSCA
29
1
/8" W x 43
3
/8" H
VRPXSCB
Architectural louver (VRP12 only) Custom Color - Special Order (30 ˚ Blade angle)
29
1
/8" W x 33
3
/8" H
Architectural louver (VRP24) Custom Color - Special Order (30 ˚ Blade angle)
(Can also be used for VRP12)
29
1
/8" W x 43
3
/8" H
42˚ blade angle louvers available by special order.
12K Louvered Grille 24K Louvered Grille
Return Air Access Panel
Figure 208 (12k and 24k Accessories Dimensional Data-Louvers & Return Access Door)
