59
EN-US
Overview of Dis-
play Values
x Optional
If the DatCom component for the required options is not available, the message
"N.A." (not available) is shown.
Display
mode
Symbol Unit Optional Display value
"Now" W - Output power
V - Grid voltage
A - Output current
Hz - Grid frequency
V - Solar module voltage
A - Solar module current
°F x solar module temperature
- - GFDI status
W x energy as read by consumption me-
ter
°F x ambient temperature
W/m² x irradiance
HH:MM x Time
"Day" kWh / MWh - Energy fed into the grid
"Year" Currency - Return
"Total" kg / T - CO
2
reduction
W - Max. output power
V - Maximum grid voltage
V - Minimum grid voltage
V - Maximum array voltage
kWh / MWh x output reading of consumption me-
ter
°F x max. solar module temperature
°F x min. solar module temperature
°F x max. ambient temperature
°F x min. ambient temperature
W/m² x max. irradiance
HH:MM - Service hours completed by the in-
verter
