4
Fit the charger to the wall using the optio-
nal wall bracket:
1. Drill two holes in the wall, insert
suitable dowels and mount wall
bracket using 2 M6 x 80 mm hexagon
screws
NOTE! If fixing to the wall, please
note the weight of the charger.
Only fix to a wall that is suitable
to this purpose.
2. Place charger on the wall bracket and
secure using the Torx screws included
with the charger.
Fitting options
Fig.4 Mounting Selectiva Plus D, 7 kW on the wall
Mounting on the
wall
557 mm
Mounting Selectiva Plus D, 7 kW on the wall
Mount the charger on the wall using the
optional fitting panels:
1. Drill holes in the wall, insert suitable
dowels and mount using 2 M6 x 80
mm hexagon screws for each panel
NOTE! If fixing to the wall, please
note the weight of the charger.
Only fix to a wall that is suitable
to this purpose.
2. Place charger on fitting panels and
secure using the Torx screws included
with the charger.
Fig. 5 Mounting Selectiva Plus D, 14 kW on the
wall
Mounting Selectiva Plus D, 14 kW on the wall
(21.93 in.)
