Settings
Advanced set-
tings
Network
The WLAN or LAN connection can be configured here. The use of a static IP ad-
dress is recommended.
Meter values
Here all values can be set to 0 or meter values can be corrected manually.
The input current of the current transformers can be changed, see Changing the
input current of the current transformers on page 49.
Software update
Software update settings can be made here. It is possible to configure an auto-
matic update.
Data interfaces
Several data interfaces can be used simultaneously.
Detailed views - Entering the login data is required.
-
Expert view: All available measured values of the Fronius Smart Meter IP are
displayed.
-
REST/JSON: The current measured data is displayed.
-
REST/XML: Only visible if the REST/XML interface is enabled under Data in-
terfaces. The current measured data is displayed.
Data interfaces
-
REST/XML: To enable the REST/XML interface.
-
Fronius Backend: A connection to a Message Queuing Telemetry Transport
(MQTT)-Broker can be set up via the Fronius backend. This setting is required
for Fronius EMIL, for example. For further information, please contact your
Fronius system partner.
-
Modbus (TCP and RTU):
-
Modbus address: Must be changed accordingly when multiple meters are
in operation (1 = primary meter)
-
Modbus TCP Port: This value must match the setting on the inverter
(standard port: 502).
Single-phase/multiphase
The connection type of the Fronius Smart Meter IP can be selected here.
Restart device
Click on Restart device to restart the Fronius Smart Meter IP.
48
