Fronius SYMO Series User Manual

Fronius Symo 10.0-3 480 12.5-3 480
Max. output power (+140 °F)
at 440 V 3200 W 3200 W
at 480 V 2900 W 2900 W
Rated apparent power 9995 VA 12,495 VA
Phases 3 ~ NPE
Nominal grid voltage
at 440 V 254 V / 440 V
at 480 V 277 V / 480 V
Operating range AC voltage -12 to +10%
Adjustment range for grid voltage 127–322 V/220–558 V
Max. continuous output current at V
nom
at 440 V 13.1 A 16.4 A
at 480 V 12.0 A 15.0 A
Recommended min. AC overcurrent protection
at 440 V 20.0 A 25.0 A
at 480 V 15.0 A 20.0 A
Max. output fault current per duration 43.1 A / 158.4 ms
Nominal frequency
50/60 Hz
Total harmonic distortion < 1.75% < 1.5%
Power factor (cos phi)
0 - 1 ind./cap.
3)
General data
Maximum efficiency 98.10%
CEC efficiency
at 440 V
at 480 V 96.50% 97.00%
Cooling Controlled forced-air ventilation
Protection class NEMA 4X
Dimensions h x w x d
28.5 x 20.1 x 8.9 in.
725 x 510 x 225 mm
Weight (full/lite version) 76.7/75.07 lbs. (34.8/34.5 kg)
Permitted ambient temperature -40 °F to +140 °F (-40 °C to +60 °C)
Permitted storage temperature -40 °F to +158 °F (-40 °C to +70 °C)
Permissible humidity 0 - 100%
Noise emission 65 dB(A) (ref. 1pW)
Protection devices
Reverse polarity protection Integrated
Stand-alone operation protection Integrated
Arc Fault Circuit Interrupter/interruption Integrated
Photovoltaic insulation monitoring Integrated
High temperature
Operating point shift/
active cooling
52

Fronius SYMO Series Specifications

General

MPPT Number	2
Frequency Range	50 / 60 Hz
Operating Temperature Range	-25°C to +60°C
Communication	WiFi, Ethernet, RS485
AC Nominal Voltage	3 x 230 V / 400 V
Output Voltage	3 x 230 V / 400 V
Warranty	5 years
